Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version

9efac65b0f30e5d43833f64f11b21c09_display_large.jpg Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_LockRing1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_Back1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_Face1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
9efac65b0f30e5d43833f64f11b21c09_display_large.jpg Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_LockRing1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_Back1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
GH10192212T_-_Face1.stl Goodson's Hobbies 1.9 Beadlock Wheel 10 Trailer Version
Advertising
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
3 files (STL) Close
  • GH10192212T_-_Back1.stl 54.0 × 54.0 × 15.5 mm
  • GH10192212T_-_Face1.stl 54.0 × 54.0 × 11.0 mm
  • GH10192212T_-_LockRing1.stl 58.5 × 58.5 × 19.8 mm

Learn more about the formats
Publication date
?
Published to Thingiverse on:
Design number 70071
Design author goodsons_hobbies
goodsons_hobbies

goodsons_hobbies

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

This beadlock wheel is for 1.9 rc crawler and scaler tires. This variation uses 4mm or 5mm x 11mm(OD) bearings in the bores of both inside and outside. This way you can mount it to spin freely on a trailer or non driven application.

File naming convention:
GHAABBCCDDT

GH= Goodson's Hobbies
AA= Wheel model #
BB= tire size 19=1.9 22=2.2
CC= wheel width (inside of front and back lip *Note: this is changed from previous wheels)
DD= back spacing, distance from outside of back to inside of hex surface
T= trailer version

For example GH08192110 = Goodson's Hobbies Model 08, 1.9 size, 21mm wide, 10mm of backspacing.

Printing:
I recommend flipping the "back" file 180 degrees to print on the flat surface. Use support on all pieces under the lips.

Recommended hardware:
5x M3x8 screws or 5x #4 x 5/16 (self tapping screw)

"How to" assembly video here:
https://youtu.be/KSv0bgMx4og

If you print it, I'd love to see it, share here, or tag me on instagram.

Find me on instagram @goodsons_hobbies
