Folding Lap Board for Dice Throne

This foldable lap board was designed for use with the Dice Throne board game as it is intended to be lightweight and easier to store, while still fitting all of the components for the game.

The lock pieces (Lock Final) snap in place and provide rigidity to the board, and the hinges (Lock Test Hinge) are held in place with small pieces of 1.75mm filament. The flip up card holders (Flip Final) snap into place and then should easily flip up for use and down for storage. The 6 panels slot together easily and can be fastened with most adhesives used for 3D prints.

Print Instructions:
You will need to print:
2x Lock Final
2x Flip Final
4x Lock Test Hinge to assemble the board

*** TO SAVE FILAMENT AND TIME PLEASE READ 3D Printing Settings***

-Generate Supports, no support interface
-Orient the Lock pieces vertically.
-Orient the hinge pieces on the side so the holes face the plate.
-Orient the Flip pieces with the dividers pointing up.
-For the Lock Final, Flip Final, and Lock Test Hinge pieces 20% infill is recommended.
-For the remaining parts 10% infill helps save filament and time, 15% adds strength.
** Reduce top and bottom layers to 4 to save time and filament**

On an Elegoo Neptune 3 I was able to print all parts in about 36 hours total. roughly 6 hours for Top parts, roughly 4 hours for Bottom parts and another 6 for the lock, hinge, and flap pieces all as one print job.
