Curb_90_Top_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_90_Bottom_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_180_Top_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_180_Bottom_v12.stl Flexible Curbs for 1:28 RC Racing Track
1000034477.jpg Flexible Curbs for 1:28 RC Racing Track
1000034478.jpg Flexible Curbs for 1:28 RC Racing Track
1000034476.jpg Flexible Curbs for 1:28 RC Racing Track
1000034475.jpg Flexible Curbs for 1:28 RC Racing Track
1000034479.jpg Flexible Curbs for 1:28 RC Racing Track
Curb_90_Top_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_90_Bottom_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_180_Top_v12.stl Flexible Curbs for 1:28 RC Racing Track
Curb_180_Bottom_v12.stl Flexible Curbs for 1:28 RC Racing Track
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 365 views
  • 0 makes
License
Usages
3D design format
4 files (STL) Close
  • Curb_180_Bottom_v12.stl 199.99424 ร— 325.81685600000003 ร— 29.5 mm
  • Curb_180_Top_v12.stl 79.99199 ร— 230.670303 ร— 29.137652 mm
  • Curb_90_Bottom_v12.stl 251.25 ร— 251.25 ร— 28.5 mm
  • Curb_90_Top_v12.stl 226.23206900000002 ร— 226.23206900000002 ร— 29.0 mm

Learn more about the formats
Publication date
Design number 4075603
Design author domi1711
domi1711

domi1711

Issue with this design? Report a problem.

3D printer file info

3D model description

We needed robust Curbs for the 90 degree and 180 degree turns on our 1:28 Indoor Track (Mini-Z, GL-Racing ...), so i came up with this design.
The Track boundaries are made of 44x24mm wood pieces (standard dimension at Hornbach, Obi : https://www.hornbach.at/p/kantholz-fichte-gehobelt-3000-x-44-x-24-mm/4005043/ ) and the curbs slide right over the wood pieces.
The Curbs themselves consist of a rigid bottom part, which can be driven on. The top part should be printed from TPU, and is designed to absorb the RC-cars energy in case of an impact.
All the parts have countersunk holes and can be screwed down with 4mm woodscrews.

3D printing settings

The Bottom part should be printed with support enabled in the area where the printed part meets the wood, standard orientation, i suggest PETG.
The top part should be printed upside down and requires no support, we used standard Bambu-TPU (not the AMS TPU, its too stiff).
