DJI Vista plus ELRS Antenna support

6c4a05eb-bb58-4948-92a3-d8edd788639d.png DJI Vista plus ELRS Antenna support
71eb094e-2bd8-4ff6-9084-363067e8e520.jpg DJI Vista plus ELRS Antenna support
Caddx_Vista_and_ELRS_antenna_support.stl DJI Vista plus ELRS Antenna support
6c4a05eb-bb58-4948-92a3-d8edd788639d.png DJI Vista plus ELRS Antenna support
71eb094e-2bd8-4ff6-9084-363067e8e520.jpg DJI Vista plus ELRS Antenna support
Caddx_Vista_and_ELRS_antenna_support.stl DJI Vista plus ELRS Antenna support
Advertising
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
3D design format
1 file Close
  • Caddx_Vista_and_ELRS_antenna_support.stl

Learn more about the formats
3D model size X 22 × Y 50 × Z 51.3 mm
Publication date
?
Published to Thingiverse on:
Design number 1195325
Design author fncesar
fncesar

fncesar

Issue with this design? Report a problem.

3D printer file info

3D model description

The combined Vista plus ELRS support will fit any drone with 4mm back struts 16mm apart.
This design caters to compact builds, where would be hard to mount both a GPS, a Vista antenna, and an ELRS one. It allows for the ELRS antenna to be parallel to a Moxon or a dipole antenna on the TX Radio. Please note reception will be better on the way out if compared to the return leg.
Anyway, this shall be better than the reception I was getting with the ELRS RX antenna mounted horizontally when the drone was sideways to the TX radio.

How to fix ELRS Antenna to Vista antenna mount: simply tape it to the flag protruding from the mount
