CHIMERA Grip (MFB Starter Pack)

NEW V4.5 UPDATE TO THE CHIMERA

Neo, Nano The Shifter, Flarespire, and myself (Jack The HANDler) have been working diligently to bring you the best grip imaginable for all generations of Beyblade.

The base dimensions of the Chimera Grip are designed around the HMS Grip by SonoKong,
which is an adult-sized "gun handle" styled shape that is incredibly comfortable to hold.

This includes the following:
- The CHIMERA (the grip itself).
- The Constellation Header (Shells that hold onto the MFB launchers from Hasbro and Takara).

V4.5 Changelog
- Fixed some issues with the rubber grip attachments not sitting properly.
- Made the connection point adjustable so that there are no more loose/ tight connections, meaning that the tightness can now be customized using an M3 hex key.(now requires 2 M3x6 hex screws and 2 m3 hex nuts for the snake/ male connecter)

Please message me (repaermirg) on Discord to pay for the files via Paypal or if you have any questions.

** REDISTRIBUTION OF STL FILES IS NOT ALLOWED.** Please support the artist!

Be sure to read the following Document too see the specifics/Instructions and Terminology:
https://docs.google.com/document/d/1d7IOEnWBMKChVKabTJcibVE9S92DmwO-rr_Hy7cC9GI/edit?tab=t.0

DISCLAIMER: We've tested the CHIMERA grip with a variety of filaments with varying results. Some filament may feel looser than others. If you've got success with a particular type, please feel free to leave the brand name in the comments for others to refer from

Print settings:
- 0.4 mm nozzle
- 0.1 / 0.15 or 0.2 mm layer high
- at least 50% infill.
- Brim highly recommended at least on outer brim only

Support settings:
- Support/object xy distance should be at 300% or 1.5 mm
- Snug Style Supports
- Top Z contact distance should be 0.2

Files already come in the correct printing position so please avoid changing them.
