  • V2 soporte antena.stl 23.99975 × 29.700001 × 11.95 mm
  • anclage puente.stl 13.0 × 30.0 × 2.5 mm
  • base puente DJI.stl 80.000002 × 30.0 × 5.0 mm

Learn more about the formats
Publication date
Design number 735733
Design author PaulDesingns
PaulDesingns

PaulDesingns

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

It is a support for the DJI Air Unit for the Atom Dauphin model, is located at the front on the porex bridge of the fuselage, we will cut and remove about 4cm central of the same bridge,

The 3D base we will present it with the thicknesses included (screwed), it is best to glue it with epoxy and once dry we can unscrew the base and proceed to mount the FPV unit to the printed bridge, we will use the same screws on one side to mount the antenna support.

(see photos)

Video: https://www.youtube.com/watch?v=dzlJdD0Y8r4

Telegram: https://telegram.me/joinchat/BnYQT0BsBlogRIeplQ3U2Q

3D printing settings

I have done it at 0.13 layer with PTG.

Page translated by automatic translation. See the original version.
