Back Cover.stl ROG Ally Dual Screen
Lower Hinge Hooks Longer.stl ROG Ally Dual Screen
PXL_20250522_083603811.MP.jpg ROG Ally Dual Screen
PXL_20250522_081931495.MP.jpg ROG Ally Dual Screen
Screenshot_20250510-010135.png ROG Ally Dual Screen
PXL_20250522_084756543.MP.jpg ROG Ally Dual Screen
PXL_20250521_075631804.MP.jpg ROG Ally Dual Screen
PXL_20250521_075604632.MP.jpg ROG Ally Dual Screen
PXL_20250521_075610921.MP.jpg ROG Ally Dual Screen
Screenshot_20250510-010050.png ROG Ally Dual Screen
Back Cover Hinge Screw on.stl ROG Ally Dual Screen
Back Cover.stl ROG Ally Dual Screen
Lower Hinge Hooks Longer.stl ROG Ally Dual Screen
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
3 files (STL) Close
  • Back Cover Hinge Screw on.stl
  • Back Cover.stl
  • Lower Hinge Hooks Longer.stl

Learn more about the formats
Publication date
Design number 3010624
Design author Jimcoo
Jimcoo

Jimcoo

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

This is a model that attaches a secondary screen to a ROG Ally. A specific case and screen is required for this to work.

I have not been able to find the screen on sale anymore, this is what my invoice says from amazon.

UPERFECT 7-inch Computer Display Portable Game Monitor 1024x600 Compatible 1920x1080 IPS LED Screen 16:9 450cd/m2 Speakers HDMI USB Wall Mounted for Raspberry Pi PS4 Xbox 360 PC Win MAC OS

ROG Ally Case
https://a.co/d/aXkBIMD

I also have a cheap HDMI hub that also fits nicely.
https://a.co/d/5bNAdJw

A few M3 screws are required. Short ones for the back cover hinge (~M3x5) and long ones for the main hinge (~M3x35).

I added 2 washers on each side of the main hinge to reduce friction.

3D printing settings

I used PETG for strength, also printed the main hinge (Lower Hinge Hooks Longer) standing up so the part would be stronger.
