HDR50 BODY KIT & MODERATOR

Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
20 files (RAR and STL) Close
  • 01_HDR50_Left_Shell.stl 26.999987 × 151.841629 × 259.12033099999996 mm
  • 02_HDR50_Right_Shell.stl 26.999987 × 151.841629 × 259.12033099999996 mm
  • 03_Alt_Moderator Part A.stl 100.94750900000001 × 57.363256 × 54.162822 mm
  • 03_Moderator Part A.stl 100.94750900000001 × 57.363256 × 52.599998 mm
  • 04_Alt_Moderator Extension Part B.stl 99.95069900000001 × 57.363256 × 57.363258 mm
  • 04_Moderator Extension Part B.stl 79.99998500000001 × 53.363256 × 49.599998 mm
  • 05_Moderator Part C.stl 12.199996999999996 × 56.808274000000004 × 49.599998 mm
  • 06_Rail Cover Part B.stl 31.149638 × 16.820249 × 216.468658 mm
  • 07_Rail Cover Part A.stl 15.442874 × 9.0 × 189.315483 mm
  • 08_Load Handle_tac.stl 15.992576 × 21.0 × 7.998634 mm
  • 09_Infill 2x.stl 69.992295 × 7.44 × 3.2 mm
  • 10 Infill 8x.stl 17.052749 × 21.458125 × 3.5 mm
  • 11_Infill 8x mirrorpart.stl 17.052749 × 21.458125 × 3.5 mm
  • 12_Alt_Extended Barrel Guide.stl 6.2 × 23.0 × 12.348674 mm
  • 12_Barrel Guide.stl 6.2 × 24.8 × 24.796488 mm
  • 13_Charge_Knob.rar
  • 13_Charge_Knob.stl 52.323677 × 35.555779 × 30.0 mm
  • 14_Buttstock01.stl 141.455885 × 162.288775 × 54.79787 mm
  • 14_Buttstock02.stl 125.204525 × 48.078032 × 40.0 mm
  • STEP files_AirbenZ_HDR50.rar

Learn more about the formats
Last update
Publication date
Design number 737069
Design author Napperd
Napperd

Napperd

Issue with this design? Report a problem.

3D printer file info

3D model description

Great new HDR50 Body Shell and Sound Moderator.

This download contains all STL as in pictures. And also STEP files (in .rar file) of all add-ons. So you can change these add-ons if you like.
Body Shells, Incl barrel guide (3 parts, L+ R) = [ STL ]
Moderator (3 parts) = [ STL + STEP ]
Picatiny rail cover (2 parts) = [ STL + STEP ]
Load handle (1 part, print twice) = [ STL + STEP ]
Infill pieces (3 parts, print multiple) = [ STL + STEP ]
Some x_Alt - files added, alternative designs. New design with barrel guide and alternative sound moderator parts
You can use it with or without Sound Moderator. Sound moderator also fits the extended barrel for HDR50!

You can choose to use the picatiny rail or the open sight rail cover.

This body can hold up to 3 magazines for your HDR50!
You need a Umarex HDR50 for this build.

You need to have some little parts, like: (Also see "Parts list")
1x M4x35 Socket head screw (for handle extension, turn the magazine-bold 180° and tap this M4 straight into the bolt (see picture). This goes easy! No drilling required!
14x M3 Socket head screws L= 12 / 16 / 20 / 30 / 50mm
15x M3 Nuts
2x Ball detents (Ball Cutters, Push Fit Ball Spring Smooth Plunger 7 × 6) : https://www.amazon.de/gp/product/B07BNH11WZ/ref=ppx_yo_dt_b_asin_title_o04_s00?ie=UTF8&psc=1

The Ø1.75mm Holes in printed parts can be used to seat pieces of filament, for 0 tolerance adjusting of 2 parts together, as you wish. Easy to build, and fun to do!

Share your make and receive all my .50 Slug downloads for free!
More add-ons coming soon!

See also my slugs for the HDR50:

3D printing settings

Your own settings for your own material.
See Parts list in pictures for more info about files and printing support.

Material I used was PLA, but use material as you prefer.
Layer height 0,2mm, but can go much smaller (High resolution STL files!).
First layer 120%
Build platform: As big as your HDR50
