Fusion 360 parametric universal project enclosure with lid

Fusion_360_parametric_universal_project_enclosure_with_lid_02.png Fusion 360 parametric universal project enclosure with lid
bbeafb5005e864feeb9c3dfe258abff1.png Fusion 360 parametric universal project enclosure with lid
b639fd833d1c9b45b052ba158ef73c5c.png Fusion 360 parametric universal project enclosure with lid
Parametric_universal_project_enclosure_with_lid_-_Lid_V1.stl Fusion 360 parametric universal project enclosure with lid
Parametric_universal_project_enclosure_with_lid_-_Base_V1.stl Fusion 360 parametric universal project enclosure with lid
Fusion_360_parametric_universal_project_enclosure_with_lid_02.png Fusion 360 parametric universal project enclosure with lid
bbeafb5005e864feeb9c3dfe258abff1.png Fusion 360 parametric universal project enclosure with lid
b639fd833d1c9b45b052ba158ef73c5c.png Fusion 360 parametric universal project enclosure with lid
Parametric_universal_project_enclosure_with_lid_-_Lid_V1.stl Fusion 360 parametric universal project enclosure with lid
Parametric_universal_project_enclosure_with_lid_-_Base_V1.stl Fusion 360 parametric universal project enclosure with lid
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
3 files Close
  • Parametric_universal_project_enclosure_with_lid.f3d
  • Parametric_universal_project_enclosure_with_lid_-_Base_V1.stl 97.400002 Γ— 53.0 Γ— 85.400002 mm
  • Parametric_universal_project_enclosure_with_lid_-_Lid_V1.stl 97.400002 Γ— 8.0 Γ— 65.400002 mm

Learn more about the formats
Publication date
?
Published to Thingiverse on:
Design number 1311739
Design author loopyengineeringco
loopyengineeringco

loopyengineeringco

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

After making the gazillionth box from scratch for my newest electronic module, I decided to parametrize (?) my latest design and save time in the future.

THERE YOU GO, YOU'RE WELCOME!

Everything is derived from the distance between the PCB mounting holes in X and in Y. So this design relies on starting with a rectangular 4x screw mounting pattern, and the posts can later be repositioned in 'Patch' mode.

So the way it works is: in Fusion360 Modelling mode > Modify > Change Parameters you input the mounting hole distances and enter the margins you want around your PCB. Everything resizes like magic :)

Check out my instagram to see it in action and the customisable parameters.
https://www.instagram.com/p/BgJiVITFWik/?hl=en&taken-by=as_motion_lab

Show me what you make with it!
