4inch Long Range Copter

A small FPV copter for the lunch break. It is designed for two 18650 vtc6 or vtc5a liion batteries.

With gps and FC stack you get a flight time of about 20min depending on throttle position. A normal speed of 35 to 40kmh is realistic at 20min flight time. Of course you can build the copter even lighter and without gps. I measured with the gps flight distance of 10km.

Here my 4inch long range FPV drone.

Its not designed for racing but "light" freestyle is possible.

I designed for long flying fun and cruising. It can easily carry a runcam thumb or similar...

Weight is about 220g. In my case i can fly 20min on two 18650 VTC6 cells.

You can build it under 200g !

• Motor: 1104 4300Kv or maybe 1405 4600kv

• Prop: 4024 Gemfan ( for the 1405 you can try 3blade)

• Fc: Mamba F405 MK2

• ESC: 15A 4in1 or 20A 4in1 Also you can use AIO FC, like Zeus10, but its designed for 20x20

• Cam: Caddx Ant

• VTX: standard cheap 20x20mm VTX of your choice

• RX: what ever you prefer ;-)

• GPS: Designed for BN-180

• Battery Mount for 18650 cells (2x)

• Battery: 2S ( 2x Quality 18650 cells like VTC6 3000mAh )

0.2mm, Petg, 25-30% infill.

Easy print no support needed.
