SideRodMountLT.stl James Webb Space Telescope Clock
SideRodMountRT.stl James Webb Space Telescope Clock
TopRodMount.stl James Webb Space Telescope Clock
SecondaryFrame.stl James Webb Space Telescope Clock
Center Leg.stl James Webb Space Telescope Clock
Side Leg.stl James Webb Space Telescope Clock
SecondaryAsmJig.stl James Webb Space Telescope Clock
Cover02.stl James Webb Space Telescope Clock
Secondary.stl James Webb Space Telescope Clock
Cover01.stl James Webb Space Telescope Clock
Primary.stl James Webb Space Telescope Clock
PrimaryCurved.stl James Webb Space Telescope Clock
IMG_1497.jpg James Webb Space Telescope Clock
IMG_1515.jpg James Webb Space Telescope Clock
IMG_1526.jpg James Webb Space Telescope Clock
IMG_1503.jpg James Webb Space Telescope Clock
IMG_1502.jpg James Webb Space Telescope Clock
IMG_1507.jpg James Webb Space Telescope Clock
JWST-Dig-01.png James Webb Space Telescope Clock
JWST-Dig-03.png James Webb Space Telescope Clock
Frame.stl James Webb Space Telescope Clock
SideRodMountLT.stl James Webb Space Telescope Clock
SideRodMountRT.stl James Webb Space Telescope Clock
TopRodMount.stl James Webb Space Telescope Clock
SecondaryFrame.stl James Webb Space Telescope Clock
Center Leg.stl James Webb Space Telescope Clock
Side Leg.stl James Webb Space Telescope Clock
SecondaryAsmJig.stl James Webb Space Telescope Clock
Cover02.stl James Webb Space Telescope Clock
Secondary.stl James Webb Space Telescope Clock
Cover01.stl James Webb Space Telescope Clock
Primary.stl James Webb Space Telescope Clock
PrimaryCurved.stl James Webb Space Telescope Clock
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
πŸ†Β BestΒ ?
License
3D design format
13 files (STL) Close
  • Center Leg.stl
  • Cover01.stl
  • Cover02.stl
  • Frame.stl
  • Primary.stl
  • PrimaryCurved.stl
  • Secondary.stl
  • SecondaryAsmJig.stl
  • SecondaryFrame.stl
  • Side Leg.stl
  • SideRodMountLT.stl
  • SideRodMountRT.stl
  • TopRodMount.stl

Learn more about the formats
Publication date
Design number 1059456
Design author timskloss
timskloss

timskloss

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

Print your own piece of science! This is a scale reproduction of the JWST telescope designed to accept a common mini clock movement. It looks otherworldly sitting on desk or on the wall. For added zing use acrylic hexagonal mirrors instead of printed ones (49.75 mm edge to edge).

The boom rods for the secondary are 4 mm diameter. Shown here are carbon fiber rods. Cut the two side rods to 270 mm and the top center rod to 282 mm.

The screws used to mount the boom mounts and legs are #4 x 3/8 inch flat head. You will need a maximum of 6 screws.

The clock movement I prefer is the Mini Quartz from ClockParts.com. Make sure to order the long shaft version 1-1/4 inch length for a scale look. Shorter shafts will work, but you will need to shorten the printing height of the center cover. The center cover should be at an equal height to the end of the clock movement shaft. You can scale the height in your slicer.

3D printing settings

No supports or special filament needed. Prints on most medium sized hobby printers. Don't adjust the scale or the clock drive won't fit properly.
Experiment with different top infill patterns to get the mirror finish you desire.
