snap-fit handle bar mount base remix (knurled, 22mm-34mm)

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.2k views
  • 2 likes
  • 37 downloads

3D model description

Modified oldcyclist's snap-fit handle bar mount base. (knurled, 22mm-34mm)
Size variations cover diameters of handlebar grip(23mm)/clamp(25-32mm) and also seatpost(27-32mm).

Use corresponding size model, less or equal to the real size. (larger size model can be broken)
ex) 25.4mm -> use 25mm model

Compatible things:
snap-fit double mount adapter by oldcyclist https://www.thingiverse.com/thing:3134648
snap-fit M5Stack cover by oldcyclist https://www.thingiverse.com/thing:3133893
Snap-fit Bike Stem Mount for Anker PowerCore 5000 / PowerCore+ mini https://www.thingiverse.com/thing:3085484

[Japanese]
oldcyclistさんのsnap-fit handle bar mount baseに滑り止めのローレット加工を追加し、一般的なハンドルのにぎり径~クランプ径(+ゴムシート分)をカバーするよう22mm~34mmサイズを作りました。シートポスト(27mm~32mm)にも使えます。(横向きになりますが)

なお、実測値以下のサイズのデータを使ってください。実測より大きいサイズだと、結束バンド穴の端の方が割れる可能性があります。

  • 3D file format: STL
  • Publication date: 2018/11/13 at 10:06
