AIM-9X Sidewinder Missile Simplified - Jet Vane & Tailfin Control Section

This is a 3D Printable SIMPLIFIED Version Control-Thrust Vectoring Section ONLY Assembly for an AIM-9X Sidewinder Missile. It's meant to be used in for parts of a full scale replica model.

This is my other AIM-9X model with most of the parts combined for easier builing and assembly. All detail is identical. There are two included versions, one with separate fasteners, and one with combined fasteners

• rendered from close up, high quality reference pictures
• very accurate geometry and dimensions
• complete fastener/hardware list, including where to get the parts
• it can be scaled to any size
• advanced experience for assembly -2 versions: one with seperate fasteners and one with all fasteners comined into the model for printing
• rendered in Fusion 360
• organized F3D file
• ALL FORMATS ARE IN .RAR FILE
• other formats at request
• minor changes to the model, if necessary, included

I use 3DXtech Carbon X -Carbon Fiber PLA. It's very rigid and gives good strength to small parts
layer height .20 for the target section main body, .16 for all other parts
if printing with carbon fiber cooling should be used for the smaller parts
