  • Box.stl 184.92955 × 114.77846199999999 × 53.049282 mm
  • Box_154.stl 153.17955 × 114.773213 × 53.046085 mm
  • Box_179.stl 178.92955 × 114.776715 × 53.046085 mm
  • Box_208.stl 206.92955 × 114.776815 × 53.046085 mm
  • Box_Husky.stl 184.589783 × 124.77671500000001 × 53.046085 mm
  • Deckel.stl 17.239531999999997 × 89.77846199999999 × 63.049282 mm
  • KTM_Airbox.3mf
  • VerbinungsStift.stl 8.026305999999977 × 34.57288 × 21.889626 mm

Learn more about the formats
Last update
Publication date
Design number 3894061
Design author oberkluber
oberkluber

oberkluber

Issue with this design? Report a problem.

3D printer file info

3D model description

This 3D‑printable modular airfilter toolbox is designed as a clever storage solution that fits into the upper part of the KTM airbox to securely carry tools, levers, spare parts, and maintenance gear without taking up backpack space — perfect for trail rides, enduro trips, and everyday maintenance.

Snap-fit lid — guarantees simple and easy access while also ensuring the box stays securely closed during hard enduro rides.

Airbox‑integrated design — mounts directly inside the KTM air filter housing using cable tie slots on the frame for a secure fit.

Quick access — easy to open and reach items even on the trail.

3 different Box heights for every printer:
1) 186mm (Box.stl)
2) 179mm (Box_179.stl)
3) 154mm (Box_154.stl)
4) 208mm (Box_208.stl)
More sizes can be added if requested.

Fitting for:
KTM EXC: 2024 | 2025 | 2026
KTM SX 2023 - 2026
KTM XC: 2023 (Box_154.stl)
Could be fitting for other models but these are known to work.

3D printing settings

Printed with:
Material: PETG
Infill: 30%
Support type: Tree

Print the parts like in the 3mf file and then assemble the lid and body by putting the connecting pin through the hole.
