Battery v-mount Body_v2.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Battery v-mount Cover_v2.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Battery v-mount 18650 Chassis.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
_DSC4245_web.jpg DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
_DSC4201.jpg DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
_DSC4207.jpg DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
_DSC4224.jpg DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Battery v-mount Body_v2.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Battery v-mount Cover_v2.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Battery v-mount 18650 Chassis.stl DIY V-Mount Battery for Broadcast Lens and Field Monitor – Affordable & Customizable Power (Under $15)
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
5 files (PDF and STL) Close
  • Battery Wiring.pdf
  • Battery v-mount 18650 Chassis.stl
  • Battery v-mount Body_v2.stl
  • Battery v-mount Cover_v2.stl
  • V-Mount Battery Parts List.pdf

Learn more about the formats
Publication date
Design number 3172133
Design author jacopotofani
jacopotofani

jacopotofani

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

This is the first self-produced, easy-to-assemble V-Mount battery. Built with a budget under $15, it offers a compact and versatile 12V power solution β€” fully adjustable from 5V to 16V depending on your needs.

The STL is designed to house a 4S lithium battery pack, offering around 50W of output power when using 18650 cells rated above 3000mAh (with a minimum continuous discharge current of ~3.5A). Perfect for small servo motors or any other 5–16V gear.

Included in the download:

Complete parts list with direct purchase links

Clear wiring diagram

STL file designed for 4S configuration

Space for a LED power button (also compatible with a basic non-LED one)

Integrated voltmeter to keep battery levels in check

By default, it powers and charges through 2-pin connectors, but the case can easily be modified to support D-Tap, DC barrel, or other custom ports.

πŸ”§ V-Mount Plate Credit:
This design uses the excellent V-Mount plate by Miguelb:
β†’ https://www.printables.com/model/463635-v-mount-plate

⚠️ Battery Safety Disclaimer:
Lithium-ion batteries can be hazardous if handled improperly. Always use a proper BMS, avoid short circuits, and never leave batteries charging unattended. This project is recommended for users familiar with electronics and battery safety.
