Hermione's Time Turner

62c66bb3-9a30-4134-bcd8-d7f0bca8a957.png Hermione's Time Turner
DiskAndGlass.stl Hermione's Time Turner
TimeTurner.stl Hermione's Time Turner
Disk.stl Hermione's Time Turner
Glass.stl Hermione's Time Turner
Rings.stl Hermione's Time Turner
62c66bb3-9a30-4134-bcd8-d7f0bca8a957.png Hermione's Time Turner
DiskAndGlass.stl Hermione's Time Turner
TimeTurner.stl Hermione's Time Turner
Disk.stl Hermione's Time Turner
Glass.stl Hermione's Time Turner
Rings.stl Hermione's Time Turner
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
5 files (STL) Close
  • Disk.stl 35.180141 Γ— 35.180144 Γ— 1.056876 mm
  • DiskAndGlass.stl 35.180141 Γ— 35.180144 Γ— 14.20032 mm
  • Glass.stl 34.315116 Γ— 14.20032 Γ— 14.20032 mm
  • Rings.stl 49.675998 Γ— 58.940476 Γ— 5.886997 mm
  • TimeTurner.stl 49.675998 Γ— 58.940476 Γ— 14.20032 mm

Learn more about the formats
Publication date
Design number 1444020
Design author Gaede-3D-Prints
Gaede-3D-Prints

Gaede-3D-Prints

Issue with this design? Report a problem.

3D printer file info

3D model description

I printed the glass in a vertical orientation with no infill and just one outer shell. As a result, it appeared transparent, resembling an actual hourglass. The disk is specifically designed to fit snugly inside the inner ring. To achieve this, I printed it separately from the glass and then made a small cut at the top. This allowed me to easily insert both the glass and the disk into the rings simultaneously. While it was possible to print all the rings at once, I found it necessary to include two tiny auxiliary disks (each measuring 0.2mm in height) under the knobs on both sides.

I also experimented with printing the glass and the disk together in a vertical orientation, although it presented some challenges.

The chain was attached independently.

3D printing settings

Material: Pla

Temperature: 200Β°C

Infill: 10%/0% as described
