Box with hangable LID and LIGHTS

This is a compact light and shadow box, wireless, and with a wall-hanging board.

The lightbox consists of 4 printed pieces:

• Box structure
• Hangable top cover
• Bottom cover
• Backplate for the lights

We've included a short video here that explains how to assemble it:

https://www.instagram.com/p/Cygxqd8rk0e/

For the assembly process, please keep the following in mind:

The box structure has a front and a back. The back is slightly triangular since it accommodates the backplate for the lights.
The top cover has an arrow indicating the direction in which it should be assembled.
The bottom cover should be placed carefully. The box structure has two rails for sliding it. We recommend pressing the battery firmly against the inside of the box before putting on the bottom cover.
The backplate for the lights goes in the triangular part of the box structure, not in the slots intended for the plates. Once the lights are in place, the excess cord can be tucked into the lower part of the slot for the sixth plate if it's not being used. If it is being used, simply place it behind the lights.

For the lights, we have used the following:

https://www.amazon.es/dp/B07FQSMFRN?ref=ppx_yo2ov_dt_b_product_details&th=1&_encoding=UTF8&tag=quimicafeina-21&linkCode=ur2&linkId=b685b4faadf8106fa635bce67e6397f8&camp=3638&creative=24630

All Quimicafeina designs are protected by Copyright Law. By downloading, you have no right to sell or distribute any digital files or reproductions from those files.

To get access to this and all of our designs or for a commercial license to sell the physical prints of the files, you can support us on patreon.

Printing settings:

Nozzle diameter: 0.4 mm
Layer height: 0.25 mm
Perimeters: 2
Top and bottom solid layers: 4
Prints with no supports
