AURA RIPPLE – Dual Shade Table Lamp | PETG + PLA | 4-Part STL

RIPPLE is a modern sculptural table lamp designed for FDM 3D printing.

Its distinctive vertical wave geometry creates an architectural silhouette while a dual-shade lighting system produces a soft, warm and dimensional glow.

The design consists of 4 separate printable parts:

• Base
• Outer Shade
• Inner Diffuser Shade
• Top Cover

The prototype shown in the photos was printed using a translucent PETG outer shade combined with a salmon-colored PLA inner diffuser. This combination allows the external shell to transmit light while the internal shade modifies and softens the color of the illumination.

The base and top cover were printed in PLA.

Unlike traditional Vase Mode lamps, the shades are designed as thin printable structures using standard FDM printing settings.

DIMENSIONS

• Outer shade height: 217 mm
• Maximum lamp width: approximately 160 mm
• Base width: approximately 160 mm
• Base height: approximately 80 mm

The model may also be scaled depending on your printer and lighting hardware.

INCLUDED STL FILES

• RIPPLE_BASE.stl
• RIPPLE_OUTER_SHADE.stl
• RIPPLE_INNER_SHADE.stl
• RIPPLE_TOP_COVER.stl

MATERIALS USED IN THE PROTOTYPE

Outer Shade
Translucent PETG

Inner Diffuser
PLA – Salmon color used in the prototype

Base
PLA

Top Cover
PLA

Different colors can be combined to create unique lighting effects.

LIGHTING

Use LED lighting only, preferably a low-temperature LED bulb.

Do not use incandescent or halogen bulbs because excessive heat may damage or deform printed plastic parts.

Electrical components, bulb, socket and cable are not included with the digital files.

LICENSE

This digital model is provided for personal use only.

You may print the model for your own personal use.

You may NOT:

• Sell physical prints of this design
• Use the model commercially
• Resell the STL files
• Share or redistribute the files
• Upload the files to another website or platform
• Distribute modified versions of the files

Original design by Glow Luminaries NY.

© Glow Luminaries NY. All rights reserved.

OUTER SHADE – TRANSLUCENT PETG

Printing mode: Standard FDM

Spiral Vase Mode: OFF

Nozzle: 0.4 mm

Layer height: 0.16–0.20 mm

Walls: 2 walls recommended

Infill: 5–10% or according to filament/transparency desired

Top layers: according to model geometry

Supports: No supports recommended for the main shade

Orientation: Vertical, as supplied

Material: Translucent PETG

For maximum light transmission, use a low infill percentage and translucent or natural PETG.

INNER DIFFUSER – PLA

Printing mode: Standard FDM

Spiral Vase Mode: OFF

Nozzle: 0.4 mm

Layer height: 0.16–0.20 mm

Walls: 2 walls recommended

Infill: 5–10%

Supports: No supports recommended

Orientation: Vertical

Material: PLA

Light or warm colors work especially well as an internal diffuser.

The prototype uses a salmon-colored PLA diffuser to create a warmer light.

BASE – PLA

Printing mode: Standard FDM

Nozzle: 0.4 mm

Layer height: 0.20 mm

Walls: 3 walls recommended

Infill: 15–20%

Supports: Only if required by your slicer

Orientation: Flat side on the build plate

Material: PLA

For additional stability, the infill can be increased.

TOP COVER – PLA

Printing mode: Standard FDM

Nozzle: 0.4 mm

Layer height: 0.16–0.20 mm

Walls: 3 walls recommended

Infill: 10–15%

Supports: Normally not required

Material: PLA

IMPORTANT

Printer tolerances vary.

Before printing the complete lamp, verify the fit of the components and adjust XY compensation or scaling slightly if necessary.

The model was designed for FDM printing and tested as a physical lamp prototype.
