Axle mounted Servo Conversion for WPL C-Series RC cars

NEW: Added a version of the mount for the Injora 7kg servo

This conversion kit allows you to change your WPL RC Car to a Axle mounted steering servo setup with the original WPL servos or others with the same dimensions. 2 versions included for printing with threaded inserts or without.
This allows for much more precise and better steering as well as more flex. I suggest to remove the Panhard bar and use it to switch to a 4-link suspension. The files where designed for the WPL C34 and C44 but should also fit the axles of other WPL RC cars.
The original servo tray will be removed and replaced by the printed front frame strut

Whats needed:
- 4x M2,5x16 screws to mount the bracket on the axle (the existing ones are a bit shorter but can be used as well)
- 4x M3x6 or M3x8 to mount the servo.
- 3x M2,5xmax.8 to mount the front frame strut

Feel free to contact me via E-mail or DM if you have questions or to order the printed models directly from me!

Follow @che.scale.models on Instagram to stay up do date.

Copyright!
All of my files are copyright protected and can´t be used for any kind of commercial use without permission. Files and printed parts can not be shared or sold.
Violation will result in legal actions being taken.
