Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
6 files (STL) Close
  • Back cover.stl 170.991264 Γ— 99.554367 Γ— 2.6000000000000014 mm
  • Body.stl 170.991264 Γ— 99.554367 Γ— 21.0 mm
  • Inside Holder down.stl 68.344506 Γ— 32.365357 Γ— 12.599999999999998 mm
  • Inside holder Up.stl 68.344506 Γ— 32.365357 Γ— 12.599999999999998 mm
  • Inside holder.stl 166.991264 Γ— 95.554367 Γ— 6.8000549999999995 mm
  • connect.stl 72.0 Γ— 135.0 Γ— 6.0 mm

Learn more about the formats
Publication date
Design number 607735
Design author SRH-EUROPE
SRH-EUROPE

SRH-EUROPE

Issue with this design? Report a problem.

3D printer file info

3D model description

DIY AIM MXS Srh-europe design

1:1 Proportional with the real AIM MXS

Build your own high quality AIM MXS for your simulator.

PARTS REQUIRED:

Vocore 5 inch display(1pcs):

https://vocore.io/screen.html

4 pin connector(1pcs):

https://es.aliexpress.com/item/32520387627.html?spm=a2g0o.productlist.0.0.459513b1akvg4Z&algo_pvid=10797efc-46a9-480e-ad54-6477957e2d90&algo_exp_id=10797efc-46a9-480e-ad54-6477957e2d90-58&pdp_ext_f=%7B%22sku_id%22%3A%2264209635900%22%7D&pdp_pi=-1%3B0.87%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

Hama Usb Hub(1pcs):

https://www.pcx.hu/hama-usb-2-0-fekete-usb-hub-200121--00793745?gclid=Cj0KCQiAuP-OBhDqARIsAD4XHpdAtoziJ7UiPHAb8oEvhi_bVktZcL0VZS3W4rSSX2VVV69LybCuxLIaAhq3EALw_wcB

Micro Usb Cable(1pcs):

https://es.aliexpress.com/item/4001205308396.html?spm=a2g0o.productlist.0.0.17b076b2GA0Yug&algo_pvid=18108c38-8f88-4669-a7d0-d000b4276e6d&algo_exp_id=18108c38-8f88-4669-a7d0-d000b4276e6d-0&pdp_ext_f=%7B%22sku_id%22%3A%2210000015701227133%22%7D&pdp_pi=-1%3B2.03%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

M3 Brass insert(4pcs):

https://es.aliexpress.com/item/4000585933306.html?spm=a2g0o.productlist.0.0.386f4b30yX6E6L&algo_pvid=72e89a71-dbae-4d46-ad58-28eb43e20f1c&algo_exp_id=72e89a71-dbae-4d46-ad58-28eb43e20f1c-0&pdp_ext_f=%7B%22sku_id%22%3A%2210000003431743857%22%7D&pdp_pi=-1%3B2.77%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

M3x10 (4pcs):

https://es.aliexpress.com/item/625792760.html?spm=a2g0o.productlist.0.0.45521152J1tgVu&algo_pvid=4203cbec-e233-491b-bf00-9fccc58d6abd&algo_exp_id=4203cbec-e233-491b-bf00-9fccc58d6abd-2&pdp_ext_f=%7B%22sku_id%22%3A%2212000021051348124%22%7D&pdp_pi=-1%3B2.14%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

M5x14mm(4pcs):

https://es.aliexpress.com/item/32966157667.html?spm=a2g0o.productlist.0.0.748e4252Cu4PO5&algo_pvid=ef7c37c1-c6b0-4607-a4f0-3a42b8683abe&algo_exp_id=ef7c37c1-c6b0-4607-a4f0-3a42b8683abe-33&pdp_ext_f=%7B%22sku_id%22%3A%2266585626954%22%7D&pdp_pi=-1%3B1.15%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

WS2812B 144 Led/M (1pcs):

https://www.amazon.com/BTF-LIGHTING-WS2812B-Individual-Addressable-Waterproof/dp/B01CDTEHRC/ref=sr_1_1_sspa?keywords=ws2812b%2B144%2Fm&qid=1642113581&sprefix=ws2812b%2B144%2Caps%2C165&sr=8-1-spons&spLa=ZW5jcnlwdGVkUXVhbGlmaWVyPUFLU1VKR1NWUU5ORFgmZW5jcnlwdGVkSWQ9QTAwMzQzNTQyR09CWkxLQVM1RDBVJmVuY3J5cHRlZEFkSWQ9QTA0NjIzMjcySDI0TlJGRFozQUtHJndpZGdldE5hbWU9c3BfYXRmJmFjdGlvbj1jbGlja1JlZGlyZWN0JmRvTm90TG9nQ2xpY2s9dHJ1ZQ&th=1

Arduino Pro micro:

https://es.aliexpress.com/item/32768308647.html?spm=a2g0o.productlist.0.0.2bb43c593q2Vxg&algo_pvid=e3938983-6d86-4354-bb11-7fd1bcb89021&algo_exp_id=e3938983-6d86-4354-bb11-7fd1bcb89021-0&pdp_ext_f=%7B%22sku_id%22%3A%2212000024349272661%22%7D&pdp_pi=-1%3B5.78%3B-1%3B-1%40salePrice%3BUSD%3Bsearch-mainSearch

Led:
https://www.youtube.com/watch?v=u5kZjg_sJdg&t=53s

Vocore:
https://www.youtube.com/watch?v=7FGX8lOgIFE

If you have more question contact me for: srheuropeeu@gmail.com

The files are for personal use only, non-commercial, not for resale!
You cannot sell the digital model, a derivative or adaptation of the model, nor can you sell prints/builds of the model.

3D printing settings

Nozzle 0.4 Layer 0.2 Infill: 30-50%
