Garmin Striker 7SV Mount for Boat Bench

Garmin Striker 7SV (9SV and probably others) Mount for Inflatable Boat Bench

This custom-designed mount is made specifically for the Garmin Striker 7SV and fits securely onto an 18 mm plywood bench typically found in inflatable boats.

🛠 Construction: Printed in PETG with 30-50% gyroid infill for strength and weather resistance.

🔩 Mounting System: The screen holder and the bench clamp both slide onto a 35 mm aluminum tube, which allows for smooth screen rotation and height adjustment.

🧵 Cable Management: The cables run cleanly through the center of the tube, hiding them from view and protecting them from damage.

🔧 Hardware Used:

M6 x 16 mm bolts (thumb screws recommended but any M6 will work) for the screen holder

Two M5 x 40 mm Allen bolts and matching nuts for the bench clamp

Perfect for anglers looking for a stable, adjustable, and clean-looking sonar mounting solution!

🧩 Print Tip: The bench holder is saved as a single STL file, but it is recommended to split it into two parts in the slicer for better print quality and strength.

🛠️ Need adjustments? I can provide custom versions to match your specific bench thickness (other than 18 mm) or a different tube diameter than 35 mm. Just let me know!
