Gyroid Dodecahedron
What does a gyroid look like in a dodecahedron? Of course, one can just print a dodecahedron using the gyroid (3D) infill while leaving the top and/or bottom open (layer=0). However, the gyroid is either too dense or not smooth. The present design takes a gyroid approximation and allows it to intersect with a dodecahedron for various views. The gyroid structure can be readily seen within the dodecahedron.
By default, the dodecahedron has an edge length of 58.78mm or a face circumradius of 50mm. It can be scaled down to, say 75% or even 25%, for small printing spaces.
Where the bottom half is exposed, minimal support is needed to support the gyroid. Otherwise, the models can be printed without support.
3D printing settings
-
3D printer file information
-
3D design format: Folder details Close
- G-DecaH_E.stl
- G-DecaH_top_open.stl
- G-DodecaH_Top_Bot_open.stl
- GDodecaH_halfOpen.stl
- G_DodecaH_0E.stl
-
Publication date:
2022-10-23 at 23:00
?
Published to Thingiverse on: 2022-10-24 at 00:50
