  • Knuckle.stl 207.583084 Γ— 180.0 Γ— 159.942635 mm
  • Lock.stl 69.0 Γ— 155.830589 Γ— 85.0 mm
  • Locklift_1.stl 39.749959000000004 Γ— 45.0 Γ— 73.633444 mm
  • Locklift_2.stl 54.0 Γ— 50.083222 Γ— 75.801475 mm
  • Locklift_3.stl 47.0 Γ— 74.99476399999999 Γ— 19.986812999999998 mm
  • Pivot pin.stl 35.928962 Γ— 224.954346 Γ— 36.0 mm

Learn more about the formats
Publication date
Design number 113078
Design author railroadlc3dp
railroadlc3dp

railroadlc3dp

Issue with this design? Report a problem.

3D printer file info

3D model description

I always wanted coupler. So I found files for AAR Type E Coupler, did little correction for printability and here it is. Files n 1:1 scale. For my print I changed scale to 30% of origina simply in Prusa slicer. Only thing you will need excepr your printed parts are two rods 2.5mm in diameted and about 1.5cm long (for 30% of original). I recomand use supports.

3D printing settings

Printer:

Prusa MK3S

Rafts:

Doesn't Matter

Supports:

Yes

Resolution:

0.15mm

Infill:

20%

Filament: PLA
