Universal Panel Support – 6 Sizes

A simple and practical support stand designed to hold large panels and sheet materials safely in a vertical position.

It can be used for doors, ceramic tiles, porcelain stoneware, MDF, particle board, plywood and other sheet materials.

The design includes six different sizes to accommodate different material thicknesses:

8 mm – thin tiles and panels

10 mm – ceramic / porcelain tiles

16 mm – MDF, particle board and similar materials

18 mm – MDF, particle board and similar materials

20 mm – thicker panels

40 mm – doors and thick boards


The triangular design provides a stable base while keeping the support compact and easy to print.

Features
- 6 sizes for different material thicknesses

- Suitable for construction and workshop use
- Designed for vertical storage and temporary support
- Compact and easy to 3D print

- Can be printed in PLA, PETG or other common materials
Useful for doors, tiles, MDF, plywood, panels and boards


Each support is marked with its corresponding size for easy identification.

Recommended print settings:

Layer height: 0.2 mm
Infill: 15–25%
Walls/perimeters: 3
Supports: Not required
Material: PLA or PETG
Nozzle: 0.4 mm
Print orientation: As shown in the model preview

The model is designed for easy 3D printing. Depending on your printer and material, minor adjustments to print settings may be required.
