Angle Grinder Disc Holder 100mm 115mm 125mm – Wall & Bench Mount

A practical 3D printable angle grinder disc storage holder designed to keep grinding, cutting and flap discs organised and easy to reach.

The holder accepts both 100 mm and 125 mm angle grinder discs, so you don't need separate holders for different disc sizes.

It can be mounted vertically on a wall or horizontally on a bench, shelf or work surface. The long central spindle keeps multiple discs together while still allowing them to be removed quickly.

Ideal for workshops, garages, fabrication shops, welding areas and tool storage.

Features
Fits 100 mm and 125 mm grinder discs
Suitable for grinding discs, cutting discs and flap discs
Holds multiple discs on one spindle
Can be wall mounted or surface/bench mounted
4 mounting holes
Reinforced spindle support
Large openings in the mounting plate reduce material and print time
Rounded edges
Simple one-piece design
No assembly required
Keeps discs off the workbench and organised
Easy to see which discs are available

The photographs show the actual printed holder being used with flap discs.

Mounting Options

Wall mounting: Mount the square plate vertically and the spindle projects horizontally. Discs simply slide onto the spindle.

Bench/shelf mounting: Fix the plate horizontally and use the spindle vertically.

This makes the same model useful in different workshop layouts.

Compatible Discs

Designed for:

100 mm / 4" discs
115 mm / 4.5" discs
125 mm / 5" discs

The central spindle passes through the standard centre opening of compatible grinder discs.

Material: PETG recommended I did mine in PLA
PLA: Suitable for normal indoor workshop use
Layer height: 0.20 mm
Nozzle: 0.4 mm
Walls: 4–5
3hour print 59 grams
Top/bottom layers: 5
Infill: 30–40%
Supports: Depending on print orientation/slicer
Brim: Optional

For heavier use, PETG with 5 walls and 40% infill would be my choice.

What's Included
Grinder disc holder STL
One-piece printable design
