Handbedruckte Duschkopfhalterung aus Harz

This 3D model is for a simple but elegant mount for a hand held shower head. It is designed to fit shower heads that use a conical nut. I designed it to print using a resin 3D-printer. I provide a pre-supported model exported from Lychee slicer as an stl. I also supply a version of the same model in stl format without supports. The conical nut that it is designed for is 38mm diameter at the base and 36.6 mm at the top with a length of 32.4mm. It is designed for a flexible hose with a diameter of 14mm. You can scale the file "hand_held_shower_head_hanger_upright.stl" to better fit the conical nut on your shower head but you will have to redo the supports. You could also probably get away with rescaling the presupported version of the file "Hanger_for_hand_held_shower_head_supported" to save yourself the bother of redoing the supports, provided the rescaling is not too great.

I have printed this on an Elegoo Jupiter 6K printer using Elegoo ABS Like grey v2.0 resin and I use a layer height of 50µm with 3s exposure time (40s exposure for the burn in layers). I printed the model solid, though you could probably get away with hollowing it. You can probably print it on an FDM printer though I haven't tried that yet. I wanted the finer finish and the more finished look of resin.
After printing and post-processing I used Gorilla Clear double sided mounting tape to attach the mount to the wall of the shower.
