A320-STYLE FULL OVERHEAD PANEL - COMPLETE SET

The complete A320 overhead, all 12 sections, as backlit light plates for
home cockpit and flight sim builders. The legends glow rather than being
printed on the surface.

PANEL

Assembled ........... 813 x 566 mm, 45.5 mm deep
Sections ............ 12
Printed parts ....... 60 (faceplate + diffuser + enclosure per module)
Controls ............ 91 (15 toggle positions, 67 pushbuttons,
9 rotary selectors)
Largest part ........ fits a 220 x 220 mm bed (Ender 3, Bambu A1, Prusa MK4)
Filament ............ roughly 3.0 kg for the whole panel

SECTIONS INCLUDED

ELEC 14 controls 420 x 150 mm 3 module(s)
AIR_COND 12 controls 420 x 170 mm 3 module(s)
ANTI_ICE_PRESS 8 controls 420 x 115 mm 3 module(s)
LIGHTS 17 controls 420 x 130 mm 3 module(s)
EVAC_EMER_PWR 6 controls 195 x 145 mm 1 module(s)
GPWS_RCDR 8 controls 195 x 130 mm 1 module(s)
OXYGEN_CALLS 7 controls 195 x 130 mm 1 module(s)
WIPER_L 2 controls 195 x 85 mm 1 module(s)
FLT_CTL 6 controls 190 x 105 mm 1 module(s)
CARGO_VENT 6 controls 190 x 140 mm 1 module(s)
ENG_START 3 controls 190 x 90 mm 1 module(s)
WIPER_R 2 controls 190 x 85 mm 1 module(s)

Centre stack is 420 mm wide and splits into 3-4 printable modules per
section; the left and right side panels are 190-195 mm and print as
single modules.

HOW THE BACKLIGHTING WORKS

Legends are recessed 0.6 mm into a 2.0 mm faceplate instead of cut
clean through, which keeps the enclosed centres of O, A, R and B attached -
cut through, they fall out of the print.

Print the base in white, then swap filament to your panel colour for the top
0.6 mm. The legends glow when lit from behind. Each enclosure has an
internal LED shelf 12 mm below the diffuser so light spreads evenly
instead of hot-spotting.

Schematic mimic lines - the AC bus bar on ELEC, the bleed duct on AIR COND -
are cut to the same depth and light up with the legends.

PRINT SETTINGS

0.4 mm nozzle, 0.2 mm layers, no supports on any part
Filament change at Z = 1.4 mm on the faceplates
Faceplate and diffuser flat; enclosures open side up

MOUNTING

Each module bolts through its four rear corner bosses into a flat backplate.
A 1:1 drilling template (SVG) is included per section - print at 100%, tape to
plywood or MDF, drill. Enclosures also carry T-tracks in the rear floor so you
can clamp to a frame anywhere along their length.

INCLUDED

STL - ready to slice
OBJ - individual parts plus assembled files with named groups
STEP - editable solid geometry
Renders, 1:1 backplate templates, and a description per section

HARDWARE REQUIRED (NOT INCLUDED)

15 x 6 mm threaded mini toggle switches (6.5 mm holes, keyed)
67 x square pushbuttons (19.5 mm aperture)
9 x rotary selectors (7.0 mm bushing)
M3 screws for the faceplates, M4 for backplate mounting
12 V LED strip for backlighting

NOTES

Product images are CG renders of the model, not photographs of a printed unit.
Switches, LEDs and electronics are not included - panels only.
Not affiliated with, endorsed by, or licensed by Airbus. A hobbyist replica
intended for flight simulation use.
