Соединенные Штаты Америки M52 Fuze

UPDATE 5-5-2026: A version compatible with M2 mortar rounds was added.

🔎General Information

This is a detailed 3D model for the ** United States M52 Fuze**. This fuze is designed for use with artillery and mortar rounds. It is suitable for 3D printing and animations.

This is the United States M52, a series of High-Explosive (HE), setback-armed, Impact (IMP) fired, Point-Detonating (PD) Mortar-Bomb fuzes. The M52 series of fuzes include the M52, M52A1, M52A1B1, M52A2, M52A2B1, M52B1, M52B2 and M52B10. The safety-wire is removed before firing. On Mortar-Bomb firing, setback drives the setback-pin rearward against its spring. This frees the spring-loaded bore-riding safety-pin, which is forced outward until it strikes the inner wall of the mortar-tube. As the fuze emerges from the mortar-tube, the safety-pin is ejected. This frees the slider which is driven by the slider spring until the detonator is aligned with the Firing-Pin (FP). Impact forces the striker rearward, driving the FP into the detonator to initiate the explosive-train.

⚠️Disclaimer: This model is intended for visual and decorative purposes only. It is non-functional and cannot be modified to operate as a real device. I am not liable for any misuse of the printed items. Rendered images with paint and markings are for illustrative purposes only. The files are provided under the Cults Private Use License.

🧩Contents (25 Parts):

This pack of the M52 fuze includes a total of 20 parts, detailed as follows: the standard M52 fuze body consists of 4 parts, including the striker cap and felt pad; the springs and safety wire are provided for reference and consist of 5 parts; the internal components consist of 11 parts; and the cutaway version is made up of 5 separate parts, provided alongside the standard model.

The model is a 1:1 scale (full scale) replica

✅Happy printing.

Have a special request or need a commercial license? Please contact me at: 3dplus.contact@proton.me

Looking for mortar rounds compatible with this fuze? Check this out.

3DPlus

Боеприпасы для 60-мм миномета M2 США (M49, M302, M83 и M69)

• 6k посмотреть
• 10 мне нравится
• 42 загрузка
• 1 коллекция
• %{всего} комплектов
• 1 kомментарий
• 2 makes

Скачать 9,35 US$

🛠️These files are optimized for smooth printing using the following settings:

• Layer Height (Resolution): 0.1 mm or lower
• Support: Yes
• Support Threshold Angle: 45°
• Wall Loops: 2
• Infill Density: 15% (Feel free to reduce it to 5% to save filament.)
• Nozzle Temperature: 220 °C (Depending on your filament.)

You should experience no printing issues with these parameters.
