Rosie the Robot

?
Качество творения: 5,0/5 (7 голоса)
Оценка участников по печатаемости, полезности, уровню детализации, т.д.

Описание 3D-модели

Rosie the Robot, from the cartoon The Jetsons, by Hanna-Barbera.

Rosie is a robot and the maid and housekeeper of the Jetson family. She is a model XB-500, an older model, but the only one U-Rent A Maid had that Jane could afford. There is an unconfirmed rumor exists that her middle name is Uniqua and she shares the surname Jetson.

No supports are required. If you have the proper filament colors, no painting is needed.

The assembled model is 225mm tall and is in proportion to my other Jetsons models.

Enjoy!

...........................................................................................................

Print Instructions:
Supports: No
Resolution: .2mm
Infill: 10%

Notes:**

Refer to the notes below for a few helpful printing and assembly instructions.

...........................................................................................................

Building the model
Colors

Black: (Paramount3D PLA - Black)
eye_blacks (contains two pieces)
wheels (contains three pieces)
body_bottom
mouth_black
body_hole_black
..

Yellow: (Paramount3D PLA - Simpson Yellow)
broom_bottom
..

Blue: (Paramount3D PLA - Cadet Blue)
head_sides (contains two pieces)
ears (contains two pieces)
body_sides (contains two pieces)
body_hole_blue
mouth_blue
wheel_base
..

White: (Paramount3D PLA - White)
hat
apron
apron_bow
cuff_left
cuff_right
collar
..

Red: (Hatchbox PLA - True Red)
eye_reds (contains two pieces)
ear_balls (contains two pieces)
arm_bolt_reds (contains two pieces)

Purple: (Gizmo Dorks ABS - Purple)
dustpan
broom_top
..

Light Blue: (Solutech ABS - Aqua Blue)
head
body_middle
arm_lower_left
arm_lower_right
arm_upper_left
arm_upper_right
arm_bolt_blues (contains two pieces)
hand_left
hand_right
..

Silver: (Polyalchemy Elixer - Silver)
pipe_a
pipe_b
pipe_c
pipe_d
pipe_e
ear_poles (contains two pieces)

Any color: (hidden piece)
cuff_pins: (contains two pieces)

...........................................................................................................

Printing and assembly tips

Printing tips
1-No supports are required.

2-There are some pieces that may need brims, use your discretion.

I used brims on the eye_blacks, ear_balls, pipe_b, pipe_d, arm_lower_left and arm_lower_right.

3-Many left/right parts are exactly the same. STL files that end in 's' all have two pieces in them (as noted in the colors section) which fit either on the left or right side.

..
Assembly tips:

1-Take your time gluing the model together and enjoy the process. There are many pieces to this model, however none of the pieces are extra small and all the parts are easy to handle and fit in place.

2-I used E6000 sticky craft glue to put this model together. The sticky glue allows more time to position the parts than a fast drying superglue. I have 'fat fingers' and a shaky hand, so the sticky glue works out best for me.

3-If you have any confusion about the position of the pipe pieces, all those parts have the print bed side facing down or away from the front. Try and keep the completed pipe fairly straight once glued. However, there is plenty of leeway to attach it later if it is not straight.

4-Personally, I glued the model together in sections and then glued the sections together. I wound up with three main parts for the final assembly. The pipes, the dustpan/broom and the completed Rosie. The final assembly is to join those three sections together.

5-Refer to the assembly diagram in the pictures section as well as the uploaded pictures for putting the model together. The model is meant to be glued.

Do not hesitate to ask questions, feedback is essential to making better models.

Информация файла 3D-принтера

  • Формат 3D-дизайна: STL Детали папки Закрыть
    • apron.stl
    • apron_bow.stl
    • arm_bolt_blues.stl
    • arm_bolt_reds.stl
    • arm_lower_left.stl
    • arm_lower_right.stl
    • arm_upper_left.stl
    • arm_upper_right.stl
    • body_bottom.stl
    • body_hole_black.stl
    • body_hole_blue.stl
    • body_middle.stl
    • body_sides.stl
    • broom_bottom.stl
    • broom_top.stl
    • collar.stl
    • cuff_left.stl
    • cuff_pins.stl
    • cuff_right.stl
    • dustpan.stl
    • ear_balls.stl
    • ear_poles.stl
    • ears.stl
    • eye_blacks.stl
    • eye_reds.stl
    • hand_left.stl
    • hand_right.stl
    • hat.stl
    • head.stl
    • head_sides.stl
    • mouth_black.stl
    • mouth_blue.stl
    • pipe_a.stl
    • pipe_b.stl
    • pipe_c.stl
    • pipe_d.stl
    • pipe_e.stl
    • wheel_base.stl
    • wheels.stl

    Узнайте больше о форматах

  • Последнее обновление: 2020-09-04 12:22
  • Дата публикации: 2020-08-31 17:27

Лицензия

CC BY NC SA

Теги

Автор

Retired software engineer, learning CAD design and 3D printing. When creating models, I strive for support free designs and fun creations.
