Колодки Шмарк

UPDATE: added less tilted version of top rear pad. (see red color pad in the pictures)

Ride like never before - ride like you've been bitten by shMark!!!

Easy to print and setup shMark Pads.
You will need to come up with optional foam/leather insert in between top pads - that's the design idea. Leather/foam pad is secured with clamp. Clamp is secured with screws (optional)

Play around with color selection for pads and inserts. You can print inserts with same color and spray paint them. Or you can ignore insert and print just main parts.

Alternative styles available:

1. There is an alternative version with concave top pad. It's optional to use it. And its hard to print so consider regular version if you don't have experience.

2. Bitten by shMark TM - creative version that was "bitten" by shMark. It's suggested to print bite insert in red to mimic blood. To print bite insert - position model as on the picture to reduce overhang.

Print Clamp with hard plastic.
The rest with TPU

If you are looking to buy Original Shark Pads from which this design was inspired from please follow this link:
https://eucmarket.com/product/adjustable-shark-pads-top-bottom/

Print first 4-10 layers with PETG and the rest with TPU A95-100
with 0.4: 3 walls, 15- 20% infill
Top 15 layers of front bottom pad recommended to have modifier for infill 30%

Consider using adaptive/variable layer height for better print quality.
