P1S 3D Printer anti-vibration

This 3D Model is made out of 8 Parts.

Its made for the P1S or 39x39cm Printer
You can print it with your P1S

Im using anti vibration legs underneith (not ncluded)

Installation Guide and Description
Thank you for purchasing this 3D model. Please read these instructions carefully before installation to ensure proper fit and secure mounting.

Preparation
Turn off and unplug your 3D printer.

Measure the distance from the corner of your printer to the wall at a 45° angle.

The parts are preset for an 11 cm distance. If your measurement differs, adjust the middle connecting part in your slicer before printing—it is designed for precise length customization.

Assembly
The bracket is mounted on the left and right sides using one 6 mm wall plug and a 4.5 mm thick screw per side.

The screw head can have a diameter of up to 0.9 cm.

Glue the frame together using super glue and let it cure overnight for best strength.

Before mounting, disconnect:

The filament tube from the extruder

Any rubber fittings or parts attached to it

The AMS unit (including its power and filament hose)

The touch display

Mounting
Align the dried frame with your printer. The rear left hole might slightly interfere during alignment—simply position the frame over it or perform small adjustments as needed.

Tighten the screws gently with a screwdriver until hand-tight. Do not overtighten.

Reconnect all removed components and check that everything moves freely.

Calibrate your printer again after installation.

Additional Notes
The middle piece is variable and must be scaled to match your wall distance before printing.

Recommended materials: PLA or PETG for stability and durability.

Allow the glue to fully cure before applying any pressure.

Once complete, the mount will fit securely and align your printer precisely.
