Modular Stackable Screw-On Storage Container System - Ø80mm

3D model descriptionModular Stackable Screw-On Storage Container System (Ø80mm)A fully customizable, threaded storage system for screws, hardware, hobby supplies, or any desktop clutter. Thanks to the modular design, you can stack them as high as you want and mix-and-match the different section heights to fit your needs.

Modular Stackable Screw-On Storage Container System - DIA 80mm (NO Support)

Free Sample Version Includes:

Base section: 40 mm height

Lid: Clean, ergonomic screw-on cap

100% Support-free printing!

NEED MORE SIZES & STACKABLE MIDDLE SECTIONS?

Get the FULL VERSION with all modular middle sections to build custom height containers!

What's included in the Full Pack:

Middle sections (stackable): 30 mm, 40 mm, 50 mm, 60 mm, 70 mm, and 100 mm heights

Combine them endlessly to match your exact storage needs!

Get the Full Version here:https://cults3d.com/en/3d-model/tool/modular-stackable-screw-on-storage-container-system-o80mm

Key Features:

100% Supportless: Optimized overhangs and threads, no support material needed.

Precision Threads: Smooth screwing experience while maintaining a strong, secure hold.

3D printing settings3D PRINTING SETTINGSGeneral Parameters:

Support: NO (100% supportless design, threads and overhangs are optimized!)

Material: PLA or PETG

Infill density: 15% - 20%

Infill pattern: Gyroid

Wall loops: at least 3 walls (crucial for durable and strong threads)

Orientation: Place all parts flat on their base (open side facing up).

Fast & Functional Profile If you need quick storage for your workshop or garage:Layer height: 0.20 mm

Speed: Default standard slicer profile speed.

Purpose: Fast print times and tough containers where utility is the main priority.

Premium Aesthetic Profile For silky-smooth threading and a flawless, high-quality look:Layer height: 0.16 mm (Highly recommended for threads, ensuring a much smoother screwing experience without catching).

Outer wall speed: Lower to 50-60 mm/s (dramatically improves surface consistency and sheen).

Wall ordering: Outer / Inner (improves dimensional accuracy for the threads).

Ironing: Enable for All top surfaces (perfect for a smooth finish on the lid and rims, use Rectilinear pattern).

Z-Seam alignment: Set to Aligned or Random. Hiding or scattering the seam prevents any seam blobs from locking or jamming the threads.
