D3P OVERHEAD MOUNT FOR CREALITY SPARKX i7 by Darren 3d Print

IMPORTANT: The D3P SparkX i7 overhead mount model is only for the overhead mount. The D3P SparkX i7 bottom riser is a separate model. Both models can be used separately or together.

To find out more about the SparkX i7 D3P bottom riser click here: https://cults3d.com/en/3d-model/tool/d3p-bottom-riser-for-anycubic-kobra-x

D3P SparkX i7 bottom riser

Find out more here: https://www.youtube.com/watch?v=BRP7ik6L2w8

FEATURES

Features of the SparkX i7 D3P overhead mount:

• Space saving CFS lite mount;

• External spool holder - can be installed on either side;

• LED LIGHTS - the overhead features slots to install 3 slim 30 cm (12 inch) LED strips (see addons below);

• cable clip system - a customizable cabling clip system to arrange the cables of the SparkX i7 D3P overhead mount;

• Sturdiness and filament efficiency - the design minimizes filament use while maintaining structural strength;

• Modular integration with the SparkX i7 D3P bottom riser. The SparkX i7 D3P bottom riser is interchangeable and can be used with my Kobra X D3P overhead mount system;

• Detailed pdf instructions with pictures and steps;

• Printing requires little or no support.

EXTERNAL COMPONENTS

The following external components are optionally required. Links and further details are provided in the assembly instruction pdf:

1x - 12 inch LED strip lights - 3 pack.

INTELLECTUAL PROPERTY

This work is licensed under the standard digital file license. You are prohibited from sharing, sub-licensing, selling, renting, hosting, transferring, reproducing or distributing the digital file or 3d printed versions of this object, as well as any other derivative work in either digital or physical form (including remixes or copying/reproducing the design by any means).you are not allowed to use the objects in any manner that involves charging money or collecting fees without permission.

ADD-ONS

The model features add-ons that are free to download on MakerWorld.

Spindle holder : https://www.crealitycloud.com/model-detail/spool-holder-d3p-overhead-mount-sparkx-i7?source=22&profileId=6a03c272158250ad6546cbbd

I will be adding to these so be sure to check back from time to time.

TECHNICAL SPECIFICATIONS

For the SparkX i7 D3P overhead mount (approximates):

Filament: 400 g (see photos for detailed filament use)

Approximate print time: 13h 55 minutes

Height added by D3P bottom riser (separate model): 10 cm (4 inches)

Height with CFS lite (without D3P bottom riser): 81 cm (32 inches)

Height with CFS lite (with D3P bottom riser): 91.5 cm (36 inches)

The D3P overhead does not increase the depth or width of the footprint of the printer

PRINT SETTINGS

IMPORTANT I upload a print setting files for all my models. The print settings has the parts positioned for correct printing.

I strongly recommended you use my print setting file. If not, I will not be able to assist you if there is an issue when printing. From experience, many of the issues with printing my models are on account of users not using my print settings.

CHANGELOG

If there are any changes to the STL files or print settings I will list them here. I recommend looking at this section prior to printing as it is the only way I can inform users of changes.

3D PRINT SETTINGS

I use the following settings and materials to print this model:

Infill % : 15% (no need for more)

Nozzle diameter: 0.4 mm

Layer height: 0.2 mm standard

Material: PLA or PETG. If you plan on using a dryer on the shelves then PETG is suggested as PLA may deform

ASSEMBLY AND INSTRUCTIONS

A detailed instruction and assembly guide with steps and pictures is available for download with the model files.

TROUBLESHOOTING

All parts and the assembly have been tested multiple times (both printing and assembly).

• Make sure your build properly cleaned and free of grease and oils before printing. This is the cause of adhesion.

• Make sure you use my print profiles/settings (the .3mf file that has multiple plates with all the parts) and that you enable support as indicated for each build plate on the build plate description.

• Filament and printer will affect tolerances however all should fit. If unsure proceed slowly and cautiously.

• If there are any changes I list them in a changelog on the model page. Please have a look at it prior to printing in the event there are any changes.

I am available to assist with any issues with this model.

The best way to reach me is through Facebook messenger - my user name is "Darren 3d print".

I thank you for your support and hope you like this model.
