Ultimate Creality K1 / K1C / K1SE / K1 Max D3D Linear X Rail Upgrade (не требуется корень и полностью совместим с CFS)

** Now Compatible with ALL Creality K1 Series Machines - K1 / K1C / K1SE & K1 Max & Fully compatible with the 2025 CFS multi colour printing upgrade **

** UPDATE Feb 2025 - Now compatible with Cartographer 90° Bed Levelling Probe **

** UPDATE June 2025 - Now compatible with the v.popular Microswiss hotend upgrade **

** UPDATE Jan 2026 - Now confirmed to be compatible with the new DXC extruder **

** UPDATE Feb 2026 - Now includes mounts for BTT Eddie bed levelling probe **

Tried of VFA issues on the Creality K1 printers?
Want a solution to remove VFA but not impact build volume?
Also want a solution which means you don't need to root your machine?

Then look no further.

I got my Creality K1 Max a few month ago and I love it, but I was disappointed with the print quality on vertical faces.
I looked around the internet to see what the options were but all the solutions I found looked expensive, required modifications to the printers firmware and generally came at a loss of build volume, so I decided to do something about it.

My goals were simple:
- Remove common VFA fault
- Remove ghosting
- Make an X rail upgrade kit that works on rooted or non-rooted machines
- No impact to X x Y print area dimensions
- Make it look close to stock and in keeping with the Creality design and less like an afterthought
- No impact to start print scripts for nozzle clean/wipe
- Make gantry lighter than stock!
- Make XY block pulleys accessible so that if a bearing fails a full strip down is not required

The design is complete and ALL goals were met!

Upgrade uses a MGN9H rail rather than a MGN12H as per other upgrade kits to save weight but is reinforced by a carbon box section for additional stiffness. This has resulted in a reduction in gantry weight by 170g vs the stock Creality design which has hugely helped print quality.

I have spent many months working on this and perfecting it. The results can be seen for yourself in the photos attached.

What you will get:
- All printed part files to print the upgrade
- Full list of hardware needed and links to where to buy
- 36 Page instruction booklet for printed part assembly and full install.

• BOM -

Printed Parts - Approx 150g of High temp filament
x4 F623ZZ (3x10x4mm) Flange bearings
x2 20T Pulleys w. 3mm bore
x1 MGN9H Linear rail - Precision Class C / Z1 Preload - 400mm K1 Max / 320mm K1/K1C/K1SE
x1 Carbon square tube 10x10x8 - 500mm
x21 Brass heat inserts M3x5mm (5mm OD)
x3 Brass heat inserts M3x3mm (5mm OD) [+x2 for Cartographer edition]
x2 M3 washer
x3 M3 Square Nut
x2 M3x6 Button/SOC Cap screw
x6 M3x10 Button/SOC Cap screw
x4 M3x14 Ultra Low Allen Head screw*
x4 M3x5 Ultra Low Allen Head screw*
x2 M3x20 Ultra Low Allen Head screw*
x1 M3x29 Ultra Low Allen Head screw*
x1 M3x30 Ultra Low Allen Head screw*
x4 M3x6 Ultra Low Allen Head screw* [Cartographer edition only]
x1 Creality Heatsink**
*To save money I ordered 30mm long Ultra Low Allen Head screws and cut them down
**Only required if you have the latest heatsink with the curved fins on the rear, see photos for more details.

** UPDATE 03.02.25 **
There are however only two drawbacks:

1. It does not work with the Creality LiDar camera as it is not possible to mount the camera in the required position due to the linear rail. For me this was not much of a problem as I had stopped using and removed the LiDar camera months beforehand. However, if you are interested in this model / upgrade but use your LiDar camera, Im sorry, this is not for you.

2. I have been made aware that Creality have changed their hotend heatsink design. If you have the latest unicorn nozzle and heatsink with the CURVED FINS on the back, below the extruder, then then you will need to replace the heatsink with the non curved version or the black and silver version. This non-curved version is available on aliexpress for approx 5USD.
   Alternativly you can trim down the curved version.
   NOTE - This only effects the latest machines with the unicorn nozzle and the NEW ALL SILVER heatsink.
   See photos above for compatibility chart.

Подходит для FDM-печати с использованием высокотемпературных и прочных материалов, таких как, ABS, ASA, ABS-GF, ABS-CF, ASA-CF и т.д. Не подходит для PLA или PETG.

Полные инструкции по окрашиванию см. в прилагаемом руководстве.
