RSC Toyota Hilux XtraCab Bobbed Topper RC4WD Trailfinder 2

Hi Everyone,
Welcome to my BOBBED bed topper design for the 1984-89 Toyota Hilux XtraCab bed by RC4WD.(For standard beds see my other design)
This design is based on the Brahma Camper Shells that were popular in the 80's and 90's in the Toyota and Ford scene.
This print requires no support and for a full walkthrough please visit the RockSlugCustoms Youtube channel in my profile.

IMPORTANT:
The length of the bed bob can be seen in pictures provided.
The length of this topper is matched to the bobbed bed that can be seen in my designs.
If you have bobbed bed to a different length I cant yet guarantee it will match to your liking however here is a guide for best results.
Print the canopy "Topper Clamp file". This is a small file but it will show you the exact length of the topper.
Find the difference in millimetre as a percentage and adjust in your slicer accordingly.
Adjust all files to match.

Guide:
-The main shell has the window panels filled in with a 0.6mm wall. This is to ad rigidity to the print for the thin structure running close to the edge of the bed.
-These panels are easily removed using a sharp utensil(my video guide described the process with in detail)
-For the best results, all parts exluding the main shell, should be printed on a smooth bed. This adds to the effect of a more realistic scale camper.
-Fuzzy skin should be applied to the outer surface of the main shell(barring the windows)
-For users with smaller printers, please use the 2-piece solution and dont use fuzzy skin as the seam may be harder to sand and make less visible(although more experienced printers than myself may know how to make it work in their favour).
-8mm Wide miniature hinges are required with a bolt hole spacing of 4.5mm. These come in pack of 20 or more on amazon for very cheap.
-For hardware I use M1.6 screws. I purchase these on amazon under titles such as phone hardware repair kits. These usually provide 100-200 screws for low cost.
-Print orientation for the main shell can be seen in the pictures.
-The locking mechanism required a lot of thought to make it as unintrusive as possible and is best explained on my YT channel so please visit :)

You're feedback and makes are much appreciated. I really hope you enjoy printing my file. I'm looking forward to seeing the unique colour combinations out there as Camper shells are a great way to add some flair to a trail rigs look.

UPDATE:
-165mm version included for those with a more extreme bobbed bed. This can be adjusted to your liking in your slicer within a few mm to match your rig

Happy Trails!
Daniel
RockSlugCustoms

For print orientation see pictures.
No supports are required for the Topper.
