Совместимая с Гвитраксом трехсторонняя плитка слияния.

This design contains a model of a three way merge tile compatible with Gravitrax.
It consists of two parts that must be printed separately and then assembled.
Optionally, the elements may be glued together, but this should not be necessary.

The models are optimized for PLA, taking material expansion into account.
The scale used is 1.0032. The Z axis is left unscaled.

Minimal support is required — only three filament changes are needed when printing a single plate with any number of tiles.

IMPORTANT: Print the tabs upside down and the tile bases in the normal orientation.
The provided 3MF file contains all settings, including seam painting, layer sections to get top layer pattern different than patter used for ball chute, and finally adaptive layer height optimized for best quality.

** NOTE: ** Though I have made a lot of effort to compensate the dimensions for each tile and type of filament, each filament may exhibit different properties, and thus the final dimensions may not be fully compatible with the original Gravitrax elements.
In such cases, it may be necessary to experiment with scaling. Take PETG models as a base for experiments.

Printer settings:
Layer height 0.16mm
Wall loops: 3
Enable support: tree.
Top layer pattern: Monotonic
Middle layer pattern: Concentric
Use prime tower and select properly matching support interface filament.
