G1 Beachcomber Repair Kit - Tires, Rollcage, Headlights

A set of replacement parts to fix up any G1 Beachcomber figure. Traced from photograps.

• Tires simply clip over the existing hubcaps and can be printed in PLA, PETG, etc. A separate version for flexible materials is also included.
• Rollcage has built-in folds so it can be printed flat and bent into shape
• Headlights must be super-glued on

layer height 0.1 mm for the rollcage, in order for the folds to work well.
2 walls, inside to outside
top and bottom pattern concentric
10% infill
print speed 15 mm/s for the wheels, 5 mm/s for the others
mouse ears at the ends of the rollcage's legs, 3mm brim for the headlights and wheels to increase buildplate adhesion.
no support
no ironing

To assemble the tires, hook one side over the bare hubcap, then push the other side over until the tire snaps on. Wiggle a bit if necessary.

Be very careful with the roll cage, it is very fragile (like the original). Use tweezers to remove it from the printbed. Foldlines of 0.3mm are built in so you can just fold the sides over. Insert the rollcage one side and one leg at a time, starting with the back legs. They are a tight fit. Use tweezers to align the legs over the holes if necessary.

To mount the headlights, hold them by the neck with tweezers, place a drop of superglue at the bottom of the neck, and hold them onto the point where the original headlights broke off for 5 to 10 seconds. For the final touch, paint the fronts light blue, and apply a coat of transparent nail polish once dried.
