1984-1989 C4 Corvette Door Panel Light Cover

Door Panel Light Cover for 1984-1989 C4 Corvettes

Replace your broken or missing light cover with this 3D printable replacement designed specifically for 1984-1989 Corvettes.

FITMENT & DEVELOPMENT
- Vehicle: C4 Corvette
- Model Years: 1984, 1985, 1986, 1987, 1988, 1989
- Test fitted on a 1985 Corvette
- Largest Dimension: 6.8"
- Print Bed Size Requirement: Double check fitment if you have a small printer

This part was reverse engineered from the OEM design

FEATURES
- I have designed this to have a thin walled section so that light can be let through even when using a solid colored filament.
- I have also created a version without the 'PUSH' engraving because I noticed that it cause some imperfections in the rest of the print.

WHAT'S INCLUDED
- 1 file drivers side with 'PUSH' text
- 1 file passenger side with 'PUSH' text
- 1 file drivers side without 'PUSH' text
- 1 file passenger side without 'PUSH' text

INSTALLATION
- Tools Required: Philips head screwdriver and pliers
- Warnings: use caution when working with the old plastics
- For the drivers side you will need to completely remove the door panel so that you can unplug the windshield wiper control.
- For the passenger side you should be able to wiggle out the door panel insert without completely removing the door panel.
- Once you have access the light housing can be removed with the Phillips screws and the pin can be removed with pliers.

IMPORTANT NOTES
- This is a 3D-printable design, not a physical part
- Results may vary depending on printed, material, and print settings

WHY WAHLSTROM WORKS?

Wahlstrom Works specializes in 3D-printable replacement, upgrade, and custom parts for classic enthusiast car. My parts are engineered around the specific vehicle they're intended for, with a focus on fitment, functionality, and real-world use.

All designs have been printed and test fit on real vehicles. Because of this, I will guarantee fitment. If you have any issues with fitment please message me and I will either correct the design as needed or refund you.

3D PRINTING INSTRUCTIONS
- Top Material Recommendations: ASA, ABS, PC, PC-CF, PA6, PA12, PA-CF, PA-GF)
- PETG is not recommended due to potential warping
- PLA suitable for test fitment only
- Walls/Perimeters: 3+
- Infill: 25%
- Supports: Required
- Print Orientation: As pictured in the listing

Post Processing

-Any part can be sanded and painting as you desire.
-If you print in ASA or ABS you can attempt acetone smoothing. Please use caution with this method as acetone can be flammable.
