HONDA SHADOW VT125 (148 деталей!)

This is replica of motorcycle HONDA SHADOW VT125.

It consists 148 parts!

But don't worry. I prepared an assembly instruction (70 slides!) which will guide you through the assembly process smoothly. There is also a movie below showing design and assembly process.

Note: there are four springs which you would need to buy in a DYI store (are not printed). The two smaller springs are used inside the lags and two bigger springs are used for dampers. You can find details in the assembly instruction.

Please note that assembly instruction was made later than the movie, therefore the assembly order in the movie does not match in some portion to the instruction. Please follow the instruction, it is more comfortable.

The scale of the model has been chosen to 1:4 to be able to print all parts at 20x20cm buildplate printers.

The model is quite big, therefore if you decide to make it, consider a location to put it on the shelf :).

Designing the model took 2.5 months!

Printing took more than 200 hours.

Preparation of assembly instruction (70 pages!) took several evenings.

While I provide the model for free, I'd appreciate a small fee through my PayPal (@tobajer) if you think it's worth it.

[UPDATE on May 31, 2021]

Be aware that a button 'Download all files' does not comprise all files in the ZIP (61 out of 89) for some reason, but you can still access missing files using '89 Thing Files' tile/button (thanks simplissime3d for pointing out).

-
