What size is the upper ribcage supposed to be? Throwing it in Prusa slicer it's not even an inch tall. Thanks in advance.
- 1 me gusta
| Licencia | |
|---|---|
| Formato de diseño 3D |
3 archivos (STL) Cerrar
|
| Última actualización | |
| Fecha de publicación | |
| Número de diseño | 480134 |
¿Te gustan Cults y quieres ayudarnos a continuar la aventura de forma independiente? Tenga en cuenta que somos un equipo pequeño de 4 personas, por lo que es muy sencillo apoyarnos para mantener la actividad y crear futuros desarrollos. Aquí hay 3 soluciones accesibles para todos:
Compartir y descargar en Cults3D garantiza que los diseños permanezcan en manos de la comunidad de creadores. Y no en las de los gigantes de la impresión 3D o del software que poseen las plataformas competidoras y que explotan los diseños para sus propios intereses comerciales.
Cults3D es un sitio independiente y autofinanciado que no rinde cuentas a ningún inversor o marca. Casi todos los ingresos del sitio se devuelven a los creadores de la plataforma*. El contenido publicado en el sitio sirve *únicamente a los intereses de sus autores** y no a los de las marcas de impresoras 3D que también desean controlar el mercado del modelismo 3D.
i just bought this and in Cura its super tiny. I enlarged the upper ribcage to 165.1mm like suggested and it is 2539.22%. the connecting rod is 10mm by 10mm but the hole on the bottom rib cage is only 8.5mm squared when i enlarge it to 2539.22%.
I can fix the connecting rod easy but will the top and bottom ribcage line up properly when i enlarge them to the same %???
I'll look into this problem and see what's going on. Thanks for letting me know and I'll message you when I've resolved the issue. Appreciate your input!
Ok I have finally finished printing this. I can confirm that the % increase in size I posted did intact line up with the post. I did have so sand it down a bit tk get it in smoothly.
As long as you increase the size of both files to the same % they will fit together. Excellent model.
Do you have recommendations for support structures to use? Mine were way overkill.
Thanks for confirming scaling the same percentage of everything will allow it to fit. I would suggest spacing your supports anywhere between 5mm to even as high at 10mm so that they are easier to break apart. Unfortunately with the way the ribcage sits you're going to need a lot of support material. You may also want to add your own supports in your slicer, so that it minimizes the amount supported.
