NXG/HDX 68 角形前握把

Good handling and leadership are essential, but even more important in a defensive situation ;)

That's why I designed an AFG specifically for the NXG/HDX 68.

Above all, the design language is based on the original repetitive stock. The grooves, which can be found again in the AFG, give it the usual good handling. The additional wings connect the handle with the gun optimally and also give it a matching look.

The AFG is a unique upgrade that gives the NXG that certain something.

UPDATE: On request, an extra rail was added to the handle, so that the mounting option of the original Repetierschafts remains despite AFG. Thus, there are now 2 versions from which you can choose.

For 3D printing, I decided to use PETG. Of course, it also works with PLA.

I printed the component quite massive. In this case, I used the following:

Nozzle: 0.4

Line width: 0.65

Layer thickness: 0.2

Wall lines: 5

Supports: enabled/ normal/ everywhere

Temp Nozzle 235C°

Temp Bed: 75C°

Attached screenshots show the orientation used.

Once the components are printed, they are still fastened with 2x M3x30mm and 1xM3x10....

(You can also simply cut one of the long screws to length).

...Connected and mounted on the repeater shaft as usual.

Ready

For Austria and Germany there is also the possibility to order the handle from me for an additional charge. This I then print in the desired material and prepare it accordingly for assembly.

For questions about printing or other concerns so feel free to contact :)
