DIN 2605-1 45-3-21.3x1.6S 弯管

The Elbow pipe DIN 2605-1 45-3-21.3x1.6S 3D model is a precise digital representation of a standardized pipe fitting used in piping systems. This model adheres to the DIN 2605-1 specification, which defines the dimensions and tolerances for seamless steel elbows. The designation "45-3-21.3x1.6S" indicates a 45-degree elbow with a nominal size of DN 20 (21.3 mm outer diameter) and a wall thickness of 1.6 mm, made from stainless steel (denoted by "S").

The 3D model accurately captures the geometry of the elbow, including its curvature, end connections, and internal bore, ensuring compatibility with other piping components. It is suitable for use in CAD software for design, simulation, and manufacturing purposes, providing engineers and designers with a reliable reference for integrating this fitting into their piping layouts. The model is ideal for industries such as oil and gas, chemical processing, and HVAC, where precise and standardized components are essential.

ABS is required
