Razor Crest The Mandalorian Screen accurate

Update: I have reworked this Design and uploaded a better Version, find it here:

https://www.thingiverse.com/thing:4607202

Its really a much better version which is more screen accurate than this one, has a better Landing gear and more details.

So I highly recoomend to print the above linked Version!

Legal stuff:
BY DOWNLOADING THE FILES FROM THINGIVERSE YOU AGREE TO THE FOLLOWING TERMS AND CONDITIONS:

The files are for private use only!
You are allowed to print parts from them for your personal use only!
You are not allowed to use this files or parts you printed with the use of this files of it in any comercial way!
If you are distributing Pictures from parts or models you build with theses files you are only allowed to to so if you are declaring the source of the design. You have to add a link to this thingiverse-thing in the description of your Fotos!
You are not allowed to copy or distribute them in any way!
You are not allowed to sell them or parts you printed from them or models you build with the use of this files!

DESCRIPTION:

This is a Fan sculpt of the Razor Crest from the series "The Mandalorian"

Thanks to the few guys who tipped me for this model.
Shame on the guys who are distributing Fotos of it without giving proper credit to the source of the design.

It comes complete with a detailed cockpit, retractable landing gear and opening front hatches and back door and a opening cockpit.

When printed in 100% it has the perfect scale for star wars legions while I added a cockpit for hasbro 3.75inch/10cm action figures. So if you are tired of waiting for hasbro labs to bring a modell print this thing and save yourself the 300+ bucks it would cost anyway.

I tried to be as screen accurate as possible using Fotos and watching the series. In two points I made changes: First the side doors had to be bigger to fit for hasbro action figures while keeping the modell at a reasonable scale which can be printed on a common 20x20x20cm printer.
Second I wanted the Landing gear to be retractable and therefore made it a little simpler.

Some words in own interest: To model the ship in 3D was no easy task, in the CAD program it has over 1000 features and many time and effort was put in it.
So please leave a like if you enjoy the photos, leave a make (and also a like) when you download and print it and consider tipping me when you print the ship. Comments are also highly welcome, if its praise or recommendations for changes.

if you Need freight crates/tanks for the model look here:

https://www.thingiverse.com/thing:4288039

Watch for the tripod laser cannon from S1E1 here:

https://www.thingiverse.com/thing:4305631

Printing Instructions:

[update 07.04.20] I added a Body which is splitted in 6 parts, named "Body_6parts x". Part 1 and 2 are the normal Body front, part 3 and 4 form the Body middle, part 5 and 6 the Body back. You Need to print eiher the 3 parts or the 6 parts of the Body. The later ones have no positioning Elements to glue them together, you are on yor own here and are only recommended for People who want to have a Shorter printing time. For a better result I recommend to use the Body consisting of the 3 parts (front/middle/back)
[update 13.6.20: Added a Remix to place the seats in the Cockpit freely and a Remix with the engine split in 4 parts each, with the tips on the wings as seperate parts for smaler Printers or guys who want to resize it to a bigger scale.]

Nearly all parts can be easily printed without supports. Only exception is the Main body front, put the overhang angle to 70% so you don´t need to much support material. 10% infill is suitable for all parts, I recommend minimum 0.8mm wall thickness. All main parts should be printed vertically in or against flight direction. You can also print the canopy vertically if you have a good adhension to the print bed, but i recommend to set the build plate adhension type in Curamaker to "brim"

All parts with a 2x or 4x in the name have to be printed that often (2 times or 4 times), the part "positioner" is needed 8 times if you want to use all of them which I recommend for easy assembly. (The red parts in the assembly instruction picture.

The 7 main parts take 8 to 14 hours for each to print, the whole printing time for all the parts is approximately 100 hours. (100% size)

If you print it in 150% (if you have a big enough printer) it also fits the 6" action figures from hasbro. Excetp of the landing gear it could be sized down to 50%, the LG may also work but I´m not sure about that.

Building instructions:

You need some 1mm wire (for example a paper clip or a thin nail) and some dymo magnets, best 9mm diameter and 3mm high which fixes the back landing gear and the doors in place.
See the building instructions picture for assembly. You need to place pieces of wire in the small holes on top of the two side doors and the back door, dymos come into the two round holes of the cockpit wall back, the right hole on the inside of the main body back and in the middle parts of the landing gear in the small pockets. Be sure that these two magnets attract each other! You also need a little piece of wire as the joint of the cockpit canopy. The rest of the assembly is pretty straightforward, first assemble the landing gears, then place them in the hull, build the cockpit and place it in the front part, add the wall in the main body middle, assemble the two wings and finaly assemble all the main parts. When using PLA a normal revell glue should be enough.

-
