Helldivers 2 LAS-7 Dagger

This model will allow you to create a cosplay prop based on the LAS-7 Dagger from Helldivers 2.

https://youtube.com/shorts/ehoQA-Zgu4U?si=ni33yID-TYpoYOGj

This item features a pull-able trigger, removable flashlight attachment, removable red dot sight, and removable cooling cell, when made properly.
Length: ~13.75"
Width: ~4.75"
Height: ~9"
Weight: ~1.63 lbs

Things you'll need:

Around ~800g filament at 20%Infill. I use PLA

Printer that can handle 220mm along the x or y and 180mm long the z axis.

10 9x3mm magnets Amazon: Circle Magnets, 9x3mm Small Round Magnetic 100 Pack | Rare Earth Neodymium Refrigerator Magnet for Home Kitchen Office School Crafts Dry Erase Board Whiteboard, Silver

1/8in thick steel rod, 5 3/4, 4 ½, & 2 2/5 inch long segments. (Homedepot: 1/8 in. x 4 ft. Plain Steel Solid Round Rod)

7x20mm spring - Can get in assorted sets. Amazon: Dianrui 300PCS Compression Springs Assortment Kit 23 Different Sizes Small Spring 304 Stainless Steel Mechanical Mini Springs for DIY Repair Project

2x 2in long #8-32 screws Amazon: Small Parts Steel Pan Head Machine Screw, Black Oxide Finish, Meets ASME B18.6.3, #2 Phillips Drive, #8-32 Thread Size, 2" Length, Fully Threaded, Import (Pack of 100)

Paints and Super Glue

Optional: Thin clear plastic for the sight lens and casting resin for the barrel lens.

The Handle.stl comes with a trigger. The Trigger.stl is so you can print the trigger separately if needed.

After painting everything separately, you'll want to set the magnets, being sure they face properly to attract so attachments hold to the Dagger. Gluing the Light Attachment together first can help.

Next lets place the trigger spring in its little hole (tweezers can help with this.) Then slot your trigger in, angling it forward so it doesn't dislodge your spring. Check to make sure the trigger slides back and forth without issue.

Then we can slide on the Main, or rear of the Dagger, gluing it in place, but being sure no glue gets anywhere near the trigger slot. You don't want your trigger getting gummed up. You can also glue in your printed sight adjustment Screw.

Next, stick the steel rods into the barrel, the 5 3/4 inch rod goes into the top hole, the 4 1/2 inch the bottom. These will then hole the Handle and Main portions together. Be sure that everything fits together before gluing.

You can also glue in place the Cooling Cell Port.

Next you can use the 2 screws to secure the build together by screwing them into the holes on either side of the prop, parallel to the barrel.

Last you can either print the Lense.stl, paint and glue in place, OR print the LensCup.stl and put a tiny bit of dyed blue casting resin to make a cooler lens. Your call.

Either way that should be about it. I'm still new to posting here so let me know if anything needs further explanation and enjoy your new LAS-7 Dagger!
