Sparco Replica

Replica Model of Sparco's Most Popular Shifter.
Naturally, the shifter might not feature the same crisp aluminium CNC finish or possess the weight in your hand. However, this 3D printed plastic version comes at a mere fraction (approximately 1/30) of the price, all the while standing its ground as a worthy contender.
The shifter has been modelled to match its true size, capturing every facet of the original design. Equipped with an M18x1 Female Thread, the gear stick should fit most vehicles. Simply locate the appropriate Male Thread suitable for your transmission shaft via the link provided: [https://cults3d.com/en/3d-model/gadget/m18x1-male-threads-for-gear-sticks].
The package includes the Sparco Gear Stick, Sparco Gear Body, Sparco S, as well as the original M2 set screw design with the Sparco Body and Sparco Insert for a BMW transmission shaft. Please find related blank inserts for your vehicle’s transmission here: [https://cults3d.com/en/3d-model/gadget/blank-tapered-shifter-inserts-20mm-45mm]. Please note that the set screw design requires three M2 set screws with a length no greater than 5mm to prevent overhangs, along with a blank transmission shaft ranging from 10-16mm in diameter.

I recommend:
20% infill to minimize print time while ensuring strength. I generally use a cubic pattern, although most patterns are sufficient.
10% support infill to reduce print material and time, whilst allowing easier removal. However, this is situational and based on your printer’s capabilities. 20% support infill can significantly increase print reliability.
Print speed of 60mm/s. Again, this is situational and based on my printer’s capabilities. Most printers are capable of higher speeds, especially their default settings, although this can lead to less reliable results. Make sure to disable or decrease acceleration to reduce abrupt movements.
Lower layer height produces greater quality but is more time-consuming. I use a .2mm layer height, which encapsulates sufficient detail.
The print takes approximately 4 hours. Normal nozzles of .4mm can replicate the design.
