BMW M47/M47N/M47N2/M57 5 Bar MAP Sensor Manifold Pressure Adapter – Threaded Version

BMW M47 5 Bar MAP Sensor Adapter Bracket (OEM Bolt Retention)

Developed following extensive design work, component sourcing and clearance testing, this adapter bracket provides a clean and reliable method of fitting a BMW 5 Bar Boost Pressure Sensor (Part No. 13628514488) to the factory rear-mounted intake manifold on BMW M47 four-cylinder diesel engines.

This revised version has been designed to retain the sensor using the original style sensor retaining bolt, eliminating the need for a longer bolt and separate nut. The result is a cleaner, more OEM-style installation.

Compatibility

Suitable for:

• BMW M47 series 4-cylinder diesel engines with a rear-mounted MAP sensor.

Not suitable for:

• BMW M57N2 engines.
• Engines fitted with a top-mounted MAP sensor.

Please Note: If your MAP sensor is mounted on the top of the intake manifold rather than the rear, this adapter is not compatible. A version for top-mounted applications is currently in development.

Sensor Compatibility

• 5 Bar Boost Pressure Sensor
• BMW Part Number: 13628514488

Additional Components Required

The following parts are required for installation:

• 1 × O-ring to seal the adapter to the intake manifold.
• 1 × O-ring to seal the 5 Bar MAP sensor within the adapter.
• Original sensor retaining bolt (or equivalent OEM-specification bolt).

These components are not included with the STL file.

Features

• Designed specifically for BMW M47 engines.
• Retains the factory rear MAP sensor location.
• Uses the original-style sensor retaining bolt.
• No extended bolt or separate retaining nut required.
• Clean, OEM-style appearance.
• CAD designed and thoroughly tested for accurate fitment.

Please verify your engine configuration before purchasing to ensure compatibility. If your vehicle uses a top-mounted MAP sensor, this adapter is not suitable for your application.

This download is supplied for personal use only.

Commercial manufacture, resale, redistribution, or inclusion in commercial products is not permitted without prior permission from the designer.

If you find this model useful, please consider leaving a rating or sharing a photo of your installation. Your feedback helps support future designs and improvements.

Print Settings & Manufacturing Instructions

This component can be printed using your preferred material; however, due to the high-pressure application, a minimum material recommendation of ABS or ASA is strongly advised.

Recommended Material Requirements

• Minimum Material: ABS or ASA
• Preferred Properties: High temperature resistance, mechanical strength, and durability.

This adapter is designed for applications experiencing boost pressures of up to 40 PSI, so material selection and print quality are critical to ensure reliability and safe operation.

Manufacturing Notes

For users who require maximum strength and long-term durability, this item will also be available as a machined metal version.

Additional components, including:

• Wiring harness adapters
• Compatible pressure sensors

will be available separately through online marketplaces.

Please ensure all components are correctly installed and tested before use.
