  • bottom cover.stl
  • button.stl
  • camera_1.stl
  • camera_2.stl
  • chassis_m1.stl
  • claw holder.stl
  • claw.stl
  • claw_core.stl
  • claw_m.stl
  • connector type 1.stl
  • ext cage.stl
  • fixing plate.stl
  • hub.stl
  • int cage.stl
  • line sensor a.stl
  • line sensor b.stl
  • poli bat1.stl
  • polibat 2.stl
  • rim.stl
  • roller.stl
  • shell.stl
  • tire.stl
  • ultrasonic_1.stl
  • ultrasonic_2.stl
  • wheel.stl

Saiba mais sobre os formatos
Última atualização
Data de publicação
Número do design 926979
Autor do design Tuitxy
Tuitxy

Tuitxy

Conta certificada
Algum problema com este design? Relatar um problema.

Informações do arquivo para impressora 3D

Descrição do modelo 3D

SMARS M1 the new generation of SMARS. Thanks to the feedbacks of the V series users, I designed a new version of SMARS. The main features of this generation are:
-Quick magnetic cover for modules and battery change
-16340 rechargeable batteries for more autonomy and flexibility
-ON/OFF button on top of the model
-Wifi, this model is ESP8266 based
-designed for 4WD but works in 2WD mod too
-Compact design.

This model includes:
-main body
-wheels
-tracks
-ultrasonic module
-infrared line module
-esp32 camera module
-servo claw
-assembly instructions
-wiring diagram
-2x demo files

To build it you will need the following components:

4x magnets 5x10
https://amzn.to/3GMVkrB
https://s.click.aliexpress.com/e/_DDAPAxt

4x magnets 6x3mm:
https://amzn.to/3PG9PSs
https://s.click.aliexpress.com/e/_DEymxyP

4x 150rpm 6V N20 motors
https://s.click.aliexpress.com/e/_Dkq31AB
https://amzn.to/3GD0U1B

1x Node MCU
https://s.click.aliexpress.com/e/_DD68FoF
https://amzn.to/3g8nmVp

1x NodeMCU shield
https://s.click.aliexpress.com/e/_DeztvCL
https://amzn.to/3EdUFOJ

3x battery contacts
https://s.click.aliexpress.com/e/_DD1eqTV
https://amzn.to/3gbK5Qq

1x battery charger
https://s.click.aliexpress.com/e/_Dkiknft
https://amzn.to/3OaRTOG

2x 16340 batteries
https://s.click.aliexpress.com/e/_DFh0GH1
https://amzn.to/3tyvOjJ

For tracks:
8x 5x10x4 bearings

http://s.click.aliexpress.com/e/niSpQUu
https://amzn.to/2YWlWT7
16x 5x8x2.5 bearings

http://s.click.aliexpress.com/e/wX8okBQ

https://amzn.to/3TGQiBw
2x silicone wristbands

http://s.click.aliexpress.com/e/c26JJes0

https://amzn.to/2H2wtSx

Modules:
Camera module
https://s.click.aliexpress.com/e/_DEdp2CJ
https://amzn.to/3GD4HMn

Claw
https://s.click.aliexpress.com/e/_DcZiXQJ
https://amzn.to/3Al1jBP

Ultrasonic
https://s.click.aliexpress.com/e/_Dde2G4P
https://amzn.to/3X8CFhd

Line sensor
https://s.click.aliexpress.com/e/_DCLfz7t
https://amzn.to/3tEInKi

Configurações de impressão 3D

0.2mm 15%infill
supports only from building plate

Página traduzida por tradução automática. Ver a versão original.

Categorias

Todas as categorias › Gadget › Computadores / Drones

Metatags

Tags

Quer apoiar a Cults?

Gosta da Cults e quer nos ajudar a continuar esta aventura de forma independente? Nós somos uma pequena equipe de 4 pessoas, por isso é muito fácil nos apoiar para continuarmos em atividade e criarmos novidades para o futuro. Aqui estão 3 opções acessíveis a todos:

  • ANÚNCIOS: Desative o bloqueador de anúncios.
  • DOAÇÃO: Fazer uma doação via Ko-Fi Doar
  • BOCA A BOCA: Convide os seus amigos para acessar e descobrir a plataforma e os arquivos 3D incríveis compartilhados pela comunidade!

Compartilhar e baixar arquivos na Cults3D garante que os designs continuem nas mãos da comunidade maker, e não nas mãos de grandes empresas de impressão ou software 3D, donos das plataformas concorrentes, que exploram os designs para seus próprios interesses comerciais.

A Cults3D um site independente e de financiamento próprio que não precisa prestar contas para nenhum investidor ou marca. Quase toda a receita do site volta para os makers da plataforma. O conteúdo publicado no site atende apenas aos interesses dos próprios criadores, e não aos das marcas de impressoras 3D que também querem controlar o mercado de modelagem 3D.
