4,7L SFF PC Case

A one piece small form factor PC case designed for all standard mini itx mainboards and half height gpus.

Super portable and fits in virtually any backpack.
Size: 252x209x90 mm

Fits:
ITX Mainboards
Up to 70mm CPU cooler, Recommended: Noctua NH-L12S
2x 80x25 Case Fans
Flex Powersupplies
Half Height GPU (5060 half height, RTX pro 4000 SFF or Pro 2000)

Required for assembly:
5x m3 Nut for case panel
9x M3 SSD/Mainboard screws for case panel and Mainboard
4x M3 Heat insert for Mainboard standoffs

Tipps: With the Noctua NH-12S as exhaust it can cool a 9950x3d really well. Installing a noctua aftermarket fan for loud flex psus can make the pc whisper quiet in case you have a noisy one. The Asus X870i with backplate fits as well, but then a 92mm Fan needs to be used when using the Noctua NH-12S as the IO and M.2 Tower interferes with the 120mm fan.

When using custom shorter cables, i recommend 20cm CPU Cable, 15mm 24 Pin Mainboard cable and 25-30mm GPU cable. Moddiy can make custom cables for any psu. It then fits a Metalfish 550W flex powersupply with cables coming off the front even better for example.

Powerbutton File is included, it fits with generic power switches (bit sanding for smooth button action) Example for a fitting switch: https://www.aliexpress.com/item/4000730494696.html
The button is glued in place, flush with the case, giving a nice pressable button.

252x210 mm print bed required. Recommended to print in PETG or PCTG, PLA will work fine as well. For 250x250 Print bed, it can be adapted manually to fit.
Ventilation holes can be printed without support. Only mainboard io shield, gpu cutout and front fan screw overhangs need supports.

To install the gpu, the metal gpu bracket needs to be unscrewed from gpu and installed first. Some brackets need small modifications. 5060 fits without modification.
