Suporte de extração para armário

This is a support designed for extractors or fans of 60x60x25. Its function is to extract the hot air inside the YOOPAI or ENDER enclosures that are based on plastic rods and thus keep it closed to print materials such as ABS or ASA.

The fundamental idea is to prevent the printer electronics from being affected by the excess heat inside the enclosure, also avoiding having to remove the electronic components such as screen, motherboar and power supply from the printer by placing them outside the enclosure.

With this fan support you will not need to disassemble your printer, or make major modifications, just place inside the fans, give them power with a 12 volt switching power supply and ready, and you can print without being worried about excess heat inside.

The names of the files, indicate the quantity of them to be printed, to fasten the covers M3x10 screws were used.

This is a support designed for extractors or fans of 60x60x25. Its function is to extract the excess hot air inside the YOOPAI or ENDER enclosures that are based on plastic rods and thus keep it closed to print materials such as ABS or ASA.

The main idea is to prevent the electronics of the printer from being affected by the excess heat inside the enclosure, also avoiding having to remove the electronic components such as screen, motherboard and power supply from the printer, placing them outside the enclosure.

With this fan support you will not need to disassemble your printer, or make major modifications, just place inside the fans, give them power with a switched 12 volt power supply and ready, and you can print without being worried about excess heat inside.

The names of the files indicate the quantity of them that must be printed, to fasten the covers M3x10 screws were used.

Printer used: Ender 5 S1

Slicer: Cura Slicer

Material: PLA, ABS, PETG...

Filling density: 60%, you can increase the strength or decrease it at your discretion.

Layer height: 0.2 mm (nozzle 0.4)

Printing speed: 100 mm/s

Support: only one of the parts needs it, tree type was used.

If you have any questions about how to print the pieces or how to assemble it just contact me.
