Sistema modular de suspensão / suporte de parede - padrão e resistente (M4 / M5 / M6)

🔧 Modular Clamp / Bracket System – Standard & Heavy Duty (M4 / M5)
📐 Description

This is a compact, modular clamping and mounting system designed for workshop, bench, jig, enclosure, and general utility use.

The parts are engineered, printed, tested, and refined for real-world use — not decorative models.
All geometry is optimised for strength, clean printing, and reliable fitment without supports.

The system includes two size variants plus an adjustable shim, allowing you to dial in spacing precisely using your slicer.

📦 What’s Included

✅ Standard size clamp/bracket

✅ Heavy-duty version (≈50% larger cross-section for increased rigidity)

✅ Left & right variants

✅ 10 mm shim file
→ slice to any thickness required (e.g. 1–10 mm) you only need the shim if your walls are not level.

✅ Clean chamfers and reinforced profiles throughout

🔩 Fastener Compatibility

Standard version:

5.5 mm clearance holes

Suitable for M4 or M5 fasteners

Heavy-duty version:

6.5 mm clearance holes

Suitable for M6 fasteners

Chamfered entries for easy alignment and clean seating

(Fasteners not included)

🛠️ Typical Uses

Bench fixtures & jigs

Enclosure mounting

Workshop organisation

General clamping and locating tasks

Custom projects where adjustable spacing is needed

📏 Dimensions

Length: 100 mm (both versions)

Heavy-duty variant scaled for increased stiffness

Shim thickness adjustable in slicer
💡 Why This Design?

This model was built to solve a real workshop need — clean, repeatable mounting with adjustable spacing — without unnecessary complexity.
The shim approach avoids forcing users into fixed spacers and makes the system far more flexible in practice. the stops on the sides stop it sliding left and right, my advice allow a bit of room so you dont have to be perfect the idea is to stop it being knocked off not a perfect fit left to right as its hard to do with a drill.
I didnt print the larger file yet but its been tested on my slicer.

⚠️ Important Printing & Use Disclaimer

This design has been engineered, printed, and tested, however final strength and performance depend on print settings, material choice, wall fixings, and the item being mounted.

Due to variations in:

3D printers and calibration

Materials (PLA, PLA+, PETG, ABS, etc.)

Infill, wall count, and layer height

Wall type and fixing method

the designer cannot guarantee load capacity in all situations.

By downloading and using this file, you acknowledge that:

You are responsible for choosing appropriate print settings and materials

You are responsible for selecting suitable wall fixings

You must assess whether the design is suitable for your intended load and environment

Always test with light loads first and increase gradually.

This model is intended for general workshop, bench, and light-to-medium mounting applications.
Use at your own discretion.

🖨️ Printing Notes

Prints flat — no supports required

Recommended:

3–4 perimeters

20–40% infill (increase for heavy loads)

Tested in PLA+; PETG / ABS / Nylon recommended for higher loads or warm environments
